High Capability Farm Machinery 12HP Mini Hand Walking Tractor , Reaper Plough Mower Optional
High Capability Farm Machinery 12HP Mini Hand Walking Tractor , Reaper Plough Mower Optional
12HP walking tractor advantages
1.resonable price with simple structure
2.suit to both farm land and garden land
3.good working function
4.reaper,pump assy,ridger,ditching,corn planter,wheat planter,plough,tiller,trailer,mower are optional
Product features:
Double eagle micro rotary tiller small and light is suitable for greenhouses Field and other small plots, cultivating weed control, add different parts can complete seeding Trenching helped ridge spraying weed control of cultivated land, and other functions
Technical data:
| Tractor Model | LM-101-12 |
| Engine Model | LE195NLD |
| Engine Type | Single, horizonta, water cooled, four stroke |
| Combustion system | Direct injection |
| Cooling way | Condensing |
| Power | 1hour: 8.91kw/12hp; 12hour: 8.1kw/11hp |
| Dimensions(L*W*H) | 2170*890*1150mm |
| Min ground distance | 210mm |
| Tread | 640-680mm |
| Weight | 280kgs |
| Semi-axis | 360mm |
| Type of Tyre | 6.00-12 |
| Tire Pressure | Field work: 80-200(0.8-2.0kgf/cm²); Transportation work: 140-200(1.4-2.0kgf/cm²) |
| Triangle belt | B1800 |
Optional tool:
| 1 | reaper 1.2m |
| reaper 1.5m | |
| 2 | pump assy |
| 3 | ridger |
| 4 | ditching |
| 5 | corn planter |
| 6 | wheat planter |
| 7 | double plough |
| 8 | single plough |
| 9 | double disc plough |
| 10 | rotary tiller 101 |
| rotary tiller 151 | |
| 11 | trailer |
| 12 | mower |
Product Characters:
Walking Tractor power tiller is dual-function product that can be operated as the towing machine as well as
driving machine. It has small and compact structure, light weight, reliable performance, long service life,
easy operation and good running ability, also they are be assemble a seating equipment for driver.
The power tiller is suitable for working in paddy field, dry field, orchard, greenhouse, hilly field. With matched
accessories and farm implement, they can be used for ploughing,harrowing,seeding, cultivating, harvesting,
drilling, ditching, transporting, irrigating, sprinkling, spraying, threshing,milling,and so on.
Main Features
1)small garden tractor is small and light with low oil consumption, high efficiency and good stability.
2)Easy to operate and suitable for working in the narrow acrid land, paddy field, orchard and vegetable greenhouse.
3)According to different demands of the users, also can used for rotary planting, shallow & deep plowing, transplanting in the paddy field, loosening the soil, atomization, watering & dewatering, sowing and exploring more lands when corresponding equipments or tool are assembled
