Mini Power Tiller/ 168F Gasoline Engine Power Tiller/ Mini Tiller for Cultivation
Specifications:
| Tiller Model | LM4.1-90 | |
| Gasoline engine | Engine model | 7HP gasoline engine |
| Engine type | OHV25°Tilt,single cylinder, Forced air cooling, 4-stroke | |
| Bore×Stroke(mm) | 70×55 | |
| Displacement(ml) | 207 | |
| Compression | 8.5:1 | |
| Starting system | Recoil start | |
| Fuel tank capacity) L | 3.6 | |
| Oil volume) L | 0.6 | |
| Rated rotary speed(r/min) | 3600 | |
| Rated output(kw) | 4 | |
| Tilling parameter | Blades | 4 pcs 3 groups |
| Tilling scope (mm) | 900 | |
| Tilling depth(mm) | ≥100 | |
| Gear Shifting | Reverse, 0, 1, 2 | |
| Driving Mode | belt | |
| Fuel consumption (Kg/kw.h) | ≤35 | |
| Working performance( hsqm/h.m) | ≥0.04 | |
| Revolutions per minute of revers gear | 73 | |
| Revolutions per minute of slow gear | 97 | |
| Revolutions per minute of fast gear | 133 | |
| Tiller details | Handle horizontal adjustment | angle±90° |
| Handle vertical adjustment | angle 60° | |
| Left Handle assessories | Clutch and stall switch | |
| Right handle assessories | Throttle | |
| Transimission type | 38 type | |
| Transimission material | cast iron | |
| Tire | 400-8 | |
| Axle Diameter | φ23 |
