Mini Diesel Good Quality Farm 10HP Small Walking Tractor Hand Operated Electric Start
Mini Diesel Good Quality Farm 10HP Small Walking Tractor Hand Operated Electric Start
Features
• Dual clutch,Easy for operation,easy to maintain
• Competive price with excellent quality
• Patent product
• Multifunctional, it can be matched with kinds of accessaries
Company Introduction:
Established in 1981, Guangzhou Laurel & Honesty Holdings is a professional manufacturer and exporter that is concerned with the design, development and production of farm machinery. We are located in Guangzhou City, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
Technical data:
| Tractor Model | LM-101-10HP condensing walking tractor |
| Engine Model | LE190NLD |
| Engine Type | Single, horizonta, water cooled, four stroke |
| Combustion system | Direct injection |
| Cooling way | Condensing |
| Power | 1hour: 7.7kw/0.5hp; 12hour: 7.0kw/9.5hp |
| Dimensions(L*W*H) | 2170*890*1150mm |
| Min ground distance | 210mm |
| Tread | 640-680mm |
| Weight | 280kgs |
| Semi-axis | 360mm |
| Type of Tyre | 6.00-12 |
| Tire Pressure | Field work: 80-200(0.8-2.0kgf/cm²); Transportation work: 140-200(1.4-2.0kgf/cm²) |
| Triangle belt | B1800 |
Our Services
1.Engineers available to service machinery overseas.
2.The warranty period:1 year.
3. 24-hour service hotline:86-20-34589926.
4. Our slogan is: with the most attentive service, the highest quality, the most reasonable prices to win your trust.
5.We use the condensing condensable gas cooled; tube-fin heat sink made of aluminum alloy; German imports fuel injector; a combination of sealing gasket and aerospace Science and Technology gumming sealing gasket.
