Solar Powered Controller Agricultural Water Pump Brushless DC Solar Submersible Pump
Price:
Negotiable
MOQ:
1 set
Delivery Time:
5-15 days according to the quantity
Brand:
Laurel
Product Description
Solar Powered Controller Brushless DC Solar Pumps for Agriculture Submersible Pump
Solar Pumping System
Laurel offer practical, professional and affrodable solar powered water pumping system to residential and commercial application.
laurel solar pumping system mainly consists of solar panels, the specialized pump inverter and water pump.
Application of Solar pumping system
Agriculture irrigation
Control of desert
Pasture Animal husbandry
Living Water Supply
Seawater Desalination
City Waterscape
DC solar submersible water pump data
| TYPE | input power | voltage | solar power | rated/ max head |
rated/ max flow |
height | weight | outlet/ diameter |
packing |
| W | V | W | m | T/H | mm | kg | mm | mm | |
| 3LP1.8-16-24-120 | 120 | DC24V |
180 | 12//16 | 0.5/1.8 | 420 | 4.6 | 32/75 | 120*120*520 |
| 3LP2-20-24-150 | 150 | 225 | 15/20 | 0.7/2.0 | 420 | 4.9 | 32/75 | 120*120*520 | |
| 3LP2.5-30-24-200 | 200 | 300 | 20/30 | 0.7/2.5 | 440 | 4.6 | 32/75 | 120*120*520 | |
| 3LP2.6-40-24-400 | 400 | 600 | 30/40 | 1/2.6 | 440 | 4.9 | 32/75 | 120*120*520 | |
| 3LP2.7-52-24-550 | 550 | 750 | 40/52 | 1/2.7 | 510 | 5.3 | 32/75 | 120*120*550 | |
| 3LP1.8-16-48-120 | 120 | DC48V |
180 | 12//16 | 0.5/1.8 | 420 | 4.6 | 32/75 | 120*120*520 |
| 3LP2-20-48-150 | 150 | 225 | 15/20 | 0.7/2.0 | 420 | 4.9 | 32/75 | 120*120*520 | |
| 3LP2.5-30-48-200 | 200 | 300 | 20/30 | 0.7/2.5 | 440 | 4.6 | 32/75 | 120*120*520 | |
| 3LP2.6-40-48-400 | 400 | 600 | 30/40 | 1/2.6 | 440 | 4.9 | 32/75 | 120*120*520 | |
| 3LP2.7-52-48-550 | 550 | 750 | 40/52 | 1/2.7 | 510 | 5.3 | 32/75 | 120*120*550 | |
| 3LP3-63-48-600 | 600 | 900 | 48/63 | 1/3.0 | 510 | 5.3 | 32/75 | 120*120*550 | |
| 3LP3-78-48-750 | 750 | 1125 | 60/78 | 1/3.0 | 510 | 5.3 | 32/75 | 120*120*550 | |
| 3LP3-22-48-300 | 300 | 450 | 16//22 | 2/3.0 | 440 | 5.3 | 32/75 | 120*120*520 | |
| 3LP4-33-48-550 | 550 | 825 | 22/33 | 2/4.0 | 510 | 5.3 | 32/75 | 120*120*550 | |
| 3LP5-40-48-750 | 750 | 1125 | 33/40 | 2/5.0 | 510 | 5.8 | 32/75 | 150*150*550 |
AC solar submersible water pump data
| TYPE | rated/max flow | rated/max head | INPUT power | SOLAR POWER | VOLTAGE | SPEED | HEIGHT | N.W. | OUTLET/DIAMETER |
| T/h | M | KW | KW | V | r/min | mm | kg | mm | |
| 3LP2-50-0.75 | 2/5 | 50/70 | 1 | 1.5 | 220V | 7200 | 430 | 5 | 32/75 |
| 3LP2-65-1.1 | 2/5 | 65/80 | 1.4 | 2.1 | 220V | 7200 | 440 | 5.1 | 32/75 |
| 3LP3-50-1.1 | 3/5 | 50/80 | 1.4 | 2.1 | 220V | 7200 | 440 | 5.1 | 32/75 |
| 3LP2-100-1.5 | 2/6 | 100/120 | 1.88 | 2.8 | 220V | 7200 | 460 | 5.3 | 32/75 |
| 3LP3-80-1.5 | 3/6 | 80/120 | 1.88 | 2.8 | 220V | 7200 | 460 | 5.3 | 32/75 |
| 3LP2-120-2.2 | 2/6 | 120/145 | 2.7 | 4 | 220/380V | 7200 | 530 | 6.5 | 32/75 |
| 3LP3-100-2.2 | 3/6 | 100/148 | 2.7 | 4 | 220/380V | 7200 | 530 | 6.5 | 32/75 |
| 3LP2-200-3 | 2/6 | 200/240 | 3.62 | 5.4 | 220/380V | 7200 | 630 | 7.5 | 32/75 |
| 3LP3-175-3 | 3/6 | 175/230 | 3.62 | 5.4 | 220/380V | 7200 | 630 | 7.5 | 32/75 |
