3.7KW Four Wheel Mobility Scooter 2 Seats 4 Wheel Electric Scooter For Goods
2 Seats 4 Wheel Electric Scooter For Goods , Four Wheel Mobility Scooters
Advantages
| 1. | Special rear axle, less noise, long life time |
| 2. | ADC motor, more powerful and durable |
| 3. | LED light |
| 4. | Strong steel frame |
| 5. | Springs hydraulic shock absorbers, more comfortable |
| 6. | Mai Xunshi independent suspension |
Dimensions
1. Length: 3580mm
2. Width: 1200mm
3. Height: 1780mm
4. Ground Clearance: 114mm
Chassis Structure
|
Rear Axle |
Special Rear Axle For Electric Vehicle |
|
Mirror |
A whole piece of glass |
|
Brake |
Four Wheel Mechanical Brake |
|
Steering System |
Bidirectional Rack And Pinion Steering System Automatic clearance compensation |
|
Front Suspension |
Independent Suspension Damper |
|
Rear Suspension |
Independent Suspension Damper |
|
Frame |
High Strength Steel |
|
Tires |
Front and Rear 18x8.50-8-4P/6P |
|
Barometric Pressure |
22 PSI |
Specifications
|
Battery Volt |
48V |
|
Motor Power |
3.7 KW |
|
Body Material |
PP engineering plastic |
|
Max. Loading |
420kg |
|
Braking Distance |
≤2.5m |
|
Turning Radius |
3.2m |
|
Forward Speed |
18-24 km/h |
|
Driving Ranges |
60-80km |
|
Chassis Ground Clearance |
114mm |
|
Net Weight without battery |
300kg |
|
Tires Internal Spacing |
Front 860mm/ Rear 970mm |
|
Max. Climbing Angle |
25° |
