Aesthetic Efficient And Firm Automobile Spoiler By Ultrasonic Puncture Welding
Aesthetic Efficient And Firm Automobile Spoiler By Ultrasonic Puncture Welding
Definition of ultrasonic auto plastic welding:
Ultrasonic welding is a high-tech technology of sintered plastic products. The use of this technology can replace past production of flux, adhesives, buckles or other mechanical fixation, thereby improving the production efficiency and reduce costs. These welders combine technical sophistication with ease of use. They can be easily integrated in your production facilities. The principle of ultrasonic welding is through the ultrasonic generator to convert high-frequency electrical energy into higher frequency mechanical movement, then mechanical movement through a set of amplitude can be changed to the transmission device to the welding head. The welding head transmits the received vibration energy to the joint portion of the workpiece to be welded, in which the vibration energy is converted into heat energy by friction and the plastic is melted. Ultrasonic not only can be used to weld hard thermoplastics, but also can process fabrics and films. ALTRASONIC will find the best solution for your thermoplastic welding needs.
Specifications:
| Gun Type | Cylinder Type | ||||||||
| Model | HS-35G | HS-28G | HS-28G | HS-20G | HS-35C | HS-28C | HS-28C | HSW60 | |
| Frequency | 35k | 28k | 28k | 20k | 35k | 28k | 28k | 60k | |
| Power | 700&1000 | 300&500 | 400&700 | 900 | 700&1000 | 300&500 | 400&700 | 500 | |
| Horn | ≤10mm | ≤10mm | ≤12mm | ≤1m | ≤10mm | ≤8mm | ≤12mm | ≤12mm | |
| Housing Diameter | 51mm | 64mm | 40mm | 40mm | 45mm | 45mm | |||
| Handle Size | 100mm×45mm×32mm | —— | —— | —— | —— | ||||
|
Weight Without Wire and Horn |
0.6kg | 1.3kg | 1.3kg | 1.5kg | 0.6kg | 0.6kg | 0.6kg | 0.6kg | |
| Digital generator | ● | ● | ● | ● | ● | — | ● | ● | |
| Analog generator | ● | ● | ● | ● | ● | ● | ● | ● | |
Gun type: in accordance with the shape design of human body engineering, ultrasonic start switch is located on the trigger, easy to grasp and use the welding operation, especially suitable for horizontal or vertical.
Cylinder type: for the appearance of design straight, ultrasonic start switch is located outside the cylinder, easy welding and hand carried, can also be installed between the on machine, welding operation for each direction.
Applications:
Electronic and electrical appliances, auto parts, clothing and packaging, textile industry, environmental industry, medical equipment,the toy industry, communications equipment and other industries.
| Toy industry | Plastic toys, water guns, aquatic life video game, children dolls, plastic gifts, etc |
| Electronic products |
Recording, audio tape boxes and core wheel, disk enclosure, board of mobile phone batteries and rectifier transformers, switches and sockets, remote control, electronic swatter, pseudo-imitation caps, etc |
| Household appliances | Electronic clock, electric trumpeter hairdryer, steam iron water tank, electric kettle air-hsiang, computer, etc |
|
Stationery, daily necessities |
Stationery, aquarium ruler, the raphe folder and shell, pen stand, cosmetics box shell,the end of the toothpaste tube seal, mirror, insulated cup, lighter, seasoning bottles sealed container |
| Car, motorcycle |
Battery, front corner lamp, rear tail light, instrument, reflectors, automotive manual welding jacket, the car door welded baffle welding, automobile, car mats welding, automotive bumper repair welding |
|
The application of the sports industry |
Table tennis, table tennis bats, badminton rackets, tennis rackets, golf clubs, pool table, treadmill roller rope skipping handle stepper, treadmill accessories, box jumps,gymnastics mats, boxing gloves, boxing sandbag Sanda protective gear, the path to indicate the brand, the X Display Stand and other sports equipment, etc |
| The packaging industry | Hollow crate welding, ziplock welded |
Competitive Advantages:
1. application in riveting, forming and welding
2. light weight, easy to take, easy to operate (handheld)
3. Equipped with welding timer
4. Easty to set time welding
5. Equipped with an overload protection circuit( Voltage, current, phase, temperature, output)
6. FET power output
7. Automatic resonance
8. Maintain the amplitude function automatically
9. Starting: achieving maximum power with 105msec
