Leather Cloth Wood Bamboo Paper Acrylic Dynamic Co2 Laser Etcher Machine 275W
80W 100W 150W 200W 275W Large Format Leather Cloth Wood Bamboo Paper Dynamic Co2 Lazer Etcher Machine
(Model:PEDB-CO2)
★ Product Introduction:
The High Productivity Dynamic Co2 Lazer Etcher Machine PEDB-CO2model Is The Ideal Solution For Marking, Engraving And Cutting Paper, Cardboard, Genuine And Synthetic Leather, Natural And Synthetic Textiles, Denim, Rubber, Wood, Acrylics, Acetates, Organic And Sensitive Materials To The Co2 Wavelength In General On Large Areas Up To 600×600 Mm.
★ Product Features:
1. PEDB-CO2 lazer etcher with digital electronics designed and manufactured by sunic laser allows outstanding laser beam quality (spot diameter≤0.15 mm) for the best cutting performances up to 400×400 mm working area. High performance dynamic bean-expander actuated by galvanometric motor, enables best in class high marking speed.
2. with the red light indication system and ccd positioning system enables the correct centering of the working path to the real position of the piece in process (optional).
3. with imported laser source(maintenance-free), provide PEDB-CO2with maximum reliability and high quality performance.
4. PEDB-CO2 lazer etcher is available with full enclosed option to meet class 1 laser product safety protection.
★ Application:
Applicable industry: This kind of CO2 lazer etcher is widely applied in glasses industry, leather products, clothing industry, wood products industry, craft gifts, packaging industry.
Applicable materials: This kind of CO2 lazer etcher is widely applied for most of the non-metallic materials, such as leather, cloth, wood, bamboo, paper, organic materials, acrylic and other.
★ Technical Parameters:
| Model specification | PEDB-CO2 lazer etcher | ||||
| Laser wavelength | 10.6um | ||||
| Laser power | 80W | 100W | 150W | 200W | 275W |
| Marking speed | ≤8000mm/s | ||||
| Minimum character | 0.1mm | ||||
| Repeat accuracy | 0.003mm | ||||
| Marking depth | Depending on the material | ||||
| Flat Marking range | ≤500*500mm | ≤600*600mm | ≤700*700mm | ≤1000*1000mm | ≤1600*1600mm |
| Carved Surface marking range | ≤400*400mm | ≤500*500mm | |||
| Operation software | High performance special laser processing software | ||||
| Operating system | Windows XP/Windows 7 | ||||
| Graphic format support | PLT,DXF,AI,SDT,BMP,JPG,JPEG,GIF,TGA,PNG,TIF,TIFF | ||||
| Software features | Special laser software, easy to operate, easy to learn, software integration, data optimization function, greatly save processing time and improve work efficiency. | ||||
| Work power | 220V/50Hz/5kVA 380V/50Hz/5kVA | ||||
| Cooling method | Constant temperature water cooling | ||||
★ Machine parts:
★ Packaging & Delivery:
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
★Competitive Advantages:
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
