High Quality Accurately Fiber Laser Engraving Machine For ABS / Metal / Alloys / Plastic
High Quality Accurately Fiber Laser Engraving Machine For ABS / Metal / Alloys / Plastic
(PEDB-9060)
★ Product Introduction
Perfect Laser after many exploration and research, the latest launch of PEDB-9060 industrial laser marking system. The laser marking system is different from the past in that it uses gantry type structure to ensure the stable operation of the machine. His large table not only meets the overall processing of large materials, but also supports multi-material stitching marking. Its appearance has broken through the limitations of the traditional machine processing format, broadened the application field of laser marking, won a broader international market, and gained more and more people's recognition.
★ Product Features
1. It uses German technology, the service life of the entire industrial laser engraving machine is more than 10 years. The laser etching system is maintenance-free and the guide can be wiped every three months.
2. The marking platform of this metal laser marking system is 900mm×600mm, which supports a large marking area and can also meet the requirements of splicing marking.
3. The metal laser etching system adopts closed processing to avoid laser damage to human body. Industrial laser engraving machine can be equipped with air purifier filter smoke, after four layers of filtration to discharge clean air. The laser etching system has a window on the panel to observe and enjoy the visual marking process.
4. It is equipped with industrial computer and display, using USB data transmission. Easy to operate.
5. Metal laser marking machine using three servomotor imported from Japan, faster than the traditional stepper motor, higher precision.
★ Application and Sample
1. Applicable Materials
The metal laser marking systems are suitable for various metals, alloys and metal oxides, ABS materials, epoxy resins, hard plastics, etc.
2. Application Field
The laser marking systems are suitable for advertising, home improvement, electrical appliances, tool accessories, creative gifts, auto parts, building materials and other industries.
★ Technical Parameters
| Product name | Industrial Laser Marking Systems | |
| Model | PEDB-9060 | |
| Laser power | 20W/30W/50W/100W | |
| Marking format | 900mm×600mm | |
| Re-position Precision | ±0.002mm | |
| Motor | Japan imported servo motor | |
| Motor Power | 1200W(3×400W) | |
| Marking speed | 6000mm/s | |
| Laser wavelength | 1064nm | |
| Beam quality | M2<1.8 | |
| Cooling method | Air cooled | |
| Total power | 3000W | |
| Overall size | 1900mm×1300mm×1870mm | |
| Air Purifier (optional) | Flow | 450m³/h |
| Noise | <60dB | |
| Power | 330W | |
| Filter size | Primary cotton filter:378×278×100mm | |
| HEPA filter (PP)× 2:378×278×50mm | ||
| Activated carbon filter × 2: 378 ×278×50mm | ||
| Weight | 36.7Kg | |
| Size | 425×315×700mm | |
| Voltage | AC 220V 50-60Hz | |
| Support file format | Supports G code, PLT code format and Engraving (ENG) format generated by various CAD/CAM soft wares such as UG, MASTERCAM, CASMATE, Art CAM, AUTOCAD, Corel Draw. | |
★ Packaging & Delivery
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
★Competitive Advantages
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
