PRY-1080S Automatic Paper Waste Stripping Machines with Single Head
Price:
USD 15000 Set
MOQ:
1 Set
Delivery Time:
30 days
Brand:
PRINTYOUNG
Product Description
PRY-1080S Paper Stripping Machine with Single Head
Features
1.Fully Automatic;
2.Single head blanking system for running sheets with nested blanks;
3.Heavy-duty,quality-built single support base;
4.Equipped with high-precision linear bearing rails and servo motors for smooth and precise movement;
5.Operator-friendly touch screen for quick and simple programing;
6.Can be customized according to customers’ job demand;
7.Adopts servo motor,double guide rail and ball screw ensure accuracy;
8.Automatic lubrication system with timely maintenance extends the service life of the machine;
9.Hydraulic system with inserted motor and oil temperature cooling fan(power 3.75kw) ensures constant and big working pressure;
10.The complete machine takes much less space and is equipped with PLC,touch screen interface in operation;
11.Used to replace manual labor,improving product quality and enterprise profit.
2.Single head blanking system for running sheets with nested blanks;
3.Heavy-duty,quality-built single support base;
4.Equipped with high-precision linear bearing rails and servo motors for smooth and precise movement;
5.Operator-friendly touch screen for quick and simple programing;
6.Can be customized according to customers’ job demand;
7.Adopts servo motor,double guide rail and ball screw ensure accuracy;
8.Automatic lubrication system with timely maintenance extends the service life of the machine;
9.Hydraulic system with inserted motor and oil temperature cooling fan(power 3.75kw) ensures constant and big working pressure;
10.The complete machine takes much less space and is equipped with PLC,touch screen interface in operation;
11.Used to replace manual labor,improving product quality and enterprise profit.
Technical Parameters
|
Model
|
PRY-1080S (single work unit)
|
|
Machine Floor Area
|
2760 * 2050 * 1950 mm
|
|
Max. Sheet Size
|
1080 * 780 mm
|
|
Min. Sheet Size
|
650 * 450 mm
|
|
Max. Pile Height
|
100 mm
|
|
Min. Pile Height
|
40 mm
|
|
Max. Blanking Size
|
450 * 450 mm
|
|
Min. Blanking Size
|
30 * 30 mm
|
|
Max. Speed
|
20 cycles/minute
|
|
Pressure
|
8 bar
|
|
Total Power
|
4.5 kw
|
|
Net Weight
|
2300 kgs
|
|
Gross Weight
|
2600 kgs
|
