ST Fiber Optic Pigtail Muticore Fiber Cable with OFNP OFNR Jacket

Price Negotiable

Price: Negotiation

MOQ: 20 pcs

Delivery Time: 2-3 days

Brand: TTI/OEM/ODM

Product Description

ST Fiber Optic Pigtail Muticore Fiber Cable with OFNP OFNR Jacket

Features:

Low insertion loss and back reflection loss

Good exchangeability

Good Durability

High temperature stability

Application:

Telecommunication networks

Active device termination

Metro

Local Area Networks (LANs)

Data processing networks

Test equipment

Premise installations

Wide Area Networks (WANs)

Specification:

Style	LC,SC,ST,FC.MU,MPO, SC/APC,FC/APC,LC/APC.MU/APC Duplex MTRJ/Female, MTRJ/Male
Fiber Type	9/125 SMF-28 or equivalent (Singlemode) OS1 50/125, 62.5/125 (Multimode) OM2&OM1 50/125, 10G (Multimode) OM3
Cable Type	Simplex, Duplex (Zipcord) Φ3.0mm, Φ2.0mm, Φ1.8mm Φ1.6mm PVC or LSZH Φ0.9mm, Φ0.6mm buffered fiber PVC or LSZH
Polishing Manner	UPC,SPC,APC (8°& 6°)
Insertion Loss	≤ 0.1dB (For Singlemode Master) ≤ 0.25dB (For Singlemode Standard) ≤ 0.25dB (For Multimode) Tested by JDS RM 3750
Return Loss (For Singlemode)	UPC ≥ 50dB SPC ≥ 55dB APC ≥ 60dB (typ.65dB) Tested by JDS RM3750
Repeatability	±0.1dB
Operating Temperature	-40C to 85C
Geometry Requirement (For Singlemode)	Ferrule Endface Radius 7mm ≤ R ≤ 12mm (For APC) 10mm ≤ R ≤ 25mm (For Standard) Apex Offset ≤ 30 μm (For Master) Apex Offset ≤ 50 μm (For Standard) Undercut -50nm ≤ U ≤ 50nm Tested by DORC ZX-1

Order Information:
