Forged Grinding Steel Ball For Ball Mill ISO9001ISO14001ISO18001 20mm-150mm
Forged Grinding Steel Ball For Ball Mill ISO9001, ISO14001, ISO18001 20mm-150mm
Grinding balls for ball mill Product Description
1.15 years on Grinding Ball manufacturing and exporting.
2. Delivery within 15 days.
3. Full transport insurance.
4. Sell to 20 countries on 5 continents.
5. One-stop grinding ball solution in Jinan zhongwei company
Grinding balls for ball mill Sizes: Φ 20-Φ 150mm
Grinding balls for ball mill Applied Fields:
1). Cement Plants
2). Mines
3). Power Stations
4). Chemical Industry
5). Machine Industry
Grinding balls for ball mill Advantage:
1) High Hardness
2) No Breakage
3) Even Wearing
4) Good Wear Resistance
Grinding balls for ball mill Packaging detail:
1) Bag (1ton/bag)
2) Iron Drum (800-950kgs/drum)
| Specification of Grinding Ball | |||
| Diameter(mm) | Diametrical Tolerance(mm) | Weight/Ball(g) | Average Number/Ton |
| Φ20 | +1.0,-1.0 | 32 | 30303 |
| Φ25 | +1.0,-1.0 | 64 | 15625 |
| Φ30 | +1.0,-1.0 | 116 | 9090 |
| Φ40 | +1.5,-1.0 | 263 | 3831 |
| Φ50 | +1.5,-1.0 | 513 | 1961 |
| Φ60 | +1.5,-1.0 | 888 | 1132 |
| Φ70 | +2.0,-1.0 | 1490 | 713 |
| Φ80 | +2.0,-1.0 | 2104 | 478 |
| Φ90 | +2.5,-1.5 | 2996 | 335 |
| Φ100 | +2.5,-1.5 | 4110 | 244 |
| Φ110 | +3.0,-1.0 | 5070 | 183 |
| Φ120 | +3.0,-1.0 | 7102 | 141 |
| Φ130 | +3.0,-1.0 | 9030 | 111 |
| Φ140 | +3.0,-1.0 | 11278 | 89 |
| Φ150 | +3.0,-1.0 | 13870 | 72 |
Grinding Balls For Ball Mill Chemical Elements( Below is common used type all over the world,if you have any other different requirement, please let me know,we can order from steel mill)
Forged Steel Balls
| Material | Chemical Elements | ||||
| C | Si | Mn | P/S | Cr | |
| 45# | 0.42-0.50 | 0.17-0.37 | 0.5-0.8 | <0.035 | <0.25 |
| 60MN | 0.55-0.65 | 0.17-0.37 | 0.7-1.0 | <0.04 | <0.25 |
| B2 | 0.72-0.85 | 0.17-0.37 | 0.7-1.0 | <0.04 | 0.4-0.6 |
| B3 | 0.5-0.8 | 1.0-1.8 | 0.4-1.0 | 0.035 | 0.5-1.0 |
Cast Iron balls
| Material | Chemical Elements | |||||
| C | Si | Mn | P | S | Cr | |
| Speical Cr 2 | 2.0-3.0 | < 1.0 | 0.5-2.0 | <0.08 | < 0.06 | > 20 |
| Speical Cr 1 | 2.0-3.0 | < 1.0 | 0.5-2.0 | <0.08 | < 0.06 | > 15 |
| High Cr | 2.0-3.2 | < 1.0 | 0.5-2.5 | <0.08 | < 0.06 | > 10 |
| Medium Cr | 2.0-3.2 | < 1.0 | 0.5-2.5 | <0.08 | < 0.06 | > 5 |
| Low Cr | 2.2-3.4 | < 1.2 | 0.5-1.5 | <0.08 | < 0.06 | 1.0-1.5 |
