6082 T6 Aluminium Truss Square Light Series Outdoor Activities Roof Truss
6082 T6 Aluminum Square Truss Light Series Outdoor Activities Roof Truss
Specification
| Size of Truss | 287x287mm | 290x290mm | 300x300mm | 305x305mm |
| Connection | Spigot | Bolt/Spigot | Bolt | Bolt |
| Truss main tube | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm | Diameter Ø 50mm , Thickness 3mm |
| Truss sub-tube | / | Diameter Ø 20mm , Thickness 2mm | Diameter Ø 25mm , Thickness 2mm | Diameter Ø 25mm , Thickness 2mm |
| Truss brace tube | Diameter Ø 20mm , Thickness 2mm | Diameter Ø 20mm , Thickness 2mm | Diameter Ø 25mm , Thickness 2mm | Diameter Ø 25mm , Thickness 2mm |
| Truss Joint | Diameter Ø 50mm | Mould die | 50x25mm | 100x10mm |
| Max Loading | 520-800kg | 720-1200kg | 600-1100kg | 640-920kg |
| Max Span | 12m | 12m | 12m | 12.2m |
Application
Indoor and outdoor performance;
Catwalk, T show, concert.
Opening ceremony
Material Guarantee 6082
The proportion of chemical composition for 6061 and 6082 is different.
One of the most significant newer alloys is 6082, similar to 6061 but with better properties.
6082 has become popular in Europe because it has higher strengths which is allowable tensile strengths are 10 to 18% higher for 6082 than 6061 and better general corrosion resistance than 6061.
6082 was adopted to be using in aviation industry.
Photos
Packing & Delivery
Why choose Ledika?
16 year's experience in truss and stage industry.
Customers from more than 150 countries.
We are manufacture, can offer you lower price.
Professional engineers offer technical support to customers.
24 hours online services from our professional foreign trade department.
All our raw material is from public company.
Our complete QC system can make sure every product with high quality.
16 years after sales service.
Choosing Ledika Truss, you will get not only the products, but also the better service, and better operating mode.
About Us
LEDIKA Flight Case & Stage Truss Co., Ltd. was established in the year of 2001, located in Guangzhou city of China.
Through 15 years development, we are becoming an integrative company on aluminum truss, layer truss, ,stage and flightase ,professionally in studying,designing,producing,renting and mounting together.
“LEDIKA”approached its brand and own its worldwide market .Specially in 2007 Shanghai Summer Special Olympics, and 2010 Asian games ,and its folding truss are used in international and gain more trust and support from all over the word.
Welcome contact us for long term cooperation!
