Portable Walkthrough Metal Detector Door 24 zones Visual Audible Alarm Metal Detectors


Features

1. Multi-zone technology: 8,24,33 detection zones,can change detection zones intelligently (upgrade technology of each zone can be provided).
2. Touch screen: 7-inch HDMI LCD touch screen,iPad interface style,easy to operate and understand.
3. IP Grade: IP55 superior waterproof performance(optional)
4. Self calibration once power on
5. Adjustable sensitivity of each detection zone
6. Multi-alarm sounds to choose
7. Operating frequency can be adjusted manually or automatically
8. Move after folded or installation(two move methods to choose)
9. Detection technology: Even detection technology,no blind spot
10. Internet technology:Remote upgrade system and remote control system
11. Working band: 100 working bands
12. Sensitivity of each detection zone:255level
13. Statistics: Record the pass and alarm numbers
14. Detection speed: more than 60 people pass and detect in 1 minute

Specification


Detection objects: knives,guns,coins          External Dimension:2250x850x500mm

Passage Dimension: 2051x710x500mm    Fold Dimension:889x606x484mm

Packing Dimension: 1000x720x590mm     Humidity: 99%, non-condensing

Working environment: -20 ℃~85 ℃           Weight: NW 48KG, GW 53KG

Input : AC 110V~240V/50Hz~60Hz           Output : DC 12V/5A 12W

Power supply: the whole system is equipped with polymer battery,life time 8,16,24,48,72

hours (optional).

Product detail

Workshop display

FAQ

1. Q:Are you manufacturer or trader?

A:We are manufacturer and have own factory in Shenzhen. Our company is a high-tech security equipment supplier who integrates the development, production and sales service of the safety inspection guard products as a whole.

2. Q:Why choose me?

A:6 years experience, has strong and professional R&D team. Meanwhile have complete CE,FCC,ROHS Ceitifications

3. Q: What’s your main product?

A:We are handling hand held metal detector, walk through metal detector
