Magnesium 44 Inch AZ31B Water Heater Anode Rod 0.84 Inch Diameter

Price Negotiable

Price: negotiable

MOQ: 10 Kilograms

Delivery Time: 1 FCL:14 Days

Brand: OEM

Product Description

Magnesium 44-Inch AZ31B Water Heater Anode Rod 0.84-Inch Diameter

Hot sale Energy efficient electric water heater anode rod

electric Water Heater Anode Rod New design

Anode rod ASTM B843-M1C /ASTM B843-AZ63B magnesium water heater anode rod (CP)

solar water heater anode magnesium rod for anti-corrossion

In our range of accessories you can order G ¾“, G1“, G 1 ¼“ and G 1 ½“ adapter. Also we offer ground cable and insulation pieces for the isolated installation.

Specification

Alloy		AZ31B	Mg-Mn	Aluminum
Chemical Composition	Aluminum	2.50-3.50%	0.01% Max	Balance
	Manganese	0.20-1.00%	0.50-1.30%	- -
	Zinc	0.60-1.40%	- -	4.00-5.00% Max
	Calcium	0.04% Max	- -	- -
	Silicon	0.10% Max	- -	0.25% Max
	Copper	0.01% Max	0.02% Max	- -
	Nickel	0.001% Max	0.001% Max	- -
	Fe	0.005% Max	0.03% Max	0.25% Max
	Sn	--	- -	0.05-0.25% Max
	Other purity(each)	--	0.05% max	- -
	Total purity	0.30% Max	0.30% Max	0.15% Max
	Remaining	Magnesium	Magnesium

Dimension and Weight

Diameter(inch)	Core eccentric(inch)	Core diameter(inch)	Straightness(inch/2 ft length)	Weight(lbs/inch)
Magnesium Extruded rod
0.0675-0.020	0.050	0.135	0.060	0.025
0.750-0.020	1/16	0.135	0.040	0.031
0.800-0.020	1/16	0.135	0.040	0.035
0.840-0.020	1/16	0.135	0.040	0.038
0.900-0.020	1/16	0.135	0.040	0.043
1.050-0.020	1/16	0.135	0.040	0.057
1.315-0.020	1/16	0.135	0.040	0.089
Aluminum Extruded rod
0.576-0.020	0.050	0.135	0.060	0.038
0.750-0.020	1/16	0.135	0.050	0.048
