Galvanized Steel Pole Polygonal Q355 with Climbing Rung and Bitumen Painted

Product Description:

The material is in accordance with NF EN 10025 Standard and NF EN 10149 Standard,it has the following property.
- Yield Strength=355N/mm2
- Toughness remains the same under 20 degrees below zero.
- Galvanization is in accordance with NFA35503 Standard Class 1.

Manufacture Tolerance
- Component Length:-25mm to 75mm
- Straightness:2mm/m
- Twisting degree:1°per 3 meters length
- Ovalisation:Maximum is 3%
- The average diameter:+/-0.5%
- Slip length:+/-150mm

Product Specification:

Features:

1. We can supply the product base on client required drawing ,but also can supply the design for any kinds of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting ,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.

2. Matercial :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3

3. deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.

4. Packing: Plastic bulble , Mat &Straw Bale or following client required

5. Length : within 16meters once forming( single section)

6. Thickness: from 1mm to 25mm

7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.

Terms and Conditions:

1. Price Term: EXW, FOB, CFR or CIF.

The price includes pole shaft, base plate, crossarm and anchor bolt.
Shipping seaport: Shanghai Seaport.
Please provide drawings if you have so that we can calculate the accurate price for you.
We also provide design according to your requests, if you don't have drawings.
2. MOQ: One 40FT Container.
