12mm Heavy Duty Double Braided Nylon Rope for Electrical Cable Pulling, Marine and Industrial Use
12mm Heavy Duty Double Braided Nylon Rope for Electrical Cable Pulling, Marine and Industrial Use
Product Overview
The 12mm Double Braided Nylon Rope is a heavy duty rope designed for electrical cable pulling, marine mooring, towing, and industrial lifting. Its double braided structure provides superior strength, durability, and shock absorption compared to regular ropes.
Key Features
-
Diameter: 12mm Double Braided Nylon Rope
-
High tensile strength for cable pulling and industrial projects
-
Excellent elasticity, absorbs shock in marine use
-
Resistant to UV, abrasion, and chemicals
-
Flexible, easy to knot and handle
Applications
-
Electrical Cable Pulling in power line and underground projects
-
Marine Use: anchoring, mooring, towing
-
Industrial Use: lifting, hauling, rigging
-
General outdoor and heavy duty applications
Date Sheet
| Diameter(mm) | Diameter(Inch) | Weight(kg/220M) | Breaking strength | |
| Polyester | Nylon | |||
| 4 | 5/32 | 2.21 | 290kg | 320kg |
| 5 | 3/16 | 3.45 | 400kg | 500kg |
| 6 | 7/32 | 4.96 | 550kg | 750kg |
| 7 | 1/4 | 6.75 | 760kg | 1000kg |
| 8 | 5/16 | 8.82 | 1000kg | 1300kg |
| 9 | 11/32 | 11.16 | 1200kg | 1700kg |
| 10 | 3/8 | 13.78 | 1600kg | 2000kg |
| 12 | 1/2 | 19.85 | 2300kg | 3000kg |
| 14 | 9/16 | 27.01 | 3100kg | 4000kg |
| 16 | 5/8 | 35.28 | 4100kg | 5300kg |
| 18 | 3/4 | 44.66 | 5000kg | 6700kg |
| 20 | 13/16 | 55.13 | 6300kg | 8200kg |
FAQ
Q1: Why choose a 12mm Double Braided Nylon Rope for cable pulling?
A: Because it is a heavy duty rope with high tensile strength and flexibility, ensuring safety and efficiency in pulling heavy electrical cables.
Q2: Can this rope be used in marine environments?
A: Yes, the 12mm Double Braided Nylon Rope is highly resistant to saltwater, UV rays, and abrasion, making it perfect for marine use.
Q3: How does double braided nylon compare to single braided rope?
A: The double braided construction offers higher strength, better durability, and improved shock absorption, making it more reliable for industrial and heavy duty applications.
Why Choose This Rope?
The 12mm Heavy Duty Double Braided Nylon Rope combines high strength, long service life, and weather resistance. It is the ideal choice for cable pulling, marine, and industrial operations where safety and reliability are critical.
