E5022NRNT Cylindrical Roller Bearing 110*170*80 mm GCr15 Steel For Metallurgical Conveyor Equipment
Price:
USD 10-20
MOQ:
1 PCS
Delivery Time:
3-5 working days
Brand:
GQZ /OEM
Product Description
E5022NRNT Cylindrical Roller Bearing 110*170*80 mm GCr15 Steel For Metallurgical Conveyor Equipment
Product Overview
- E5022NRNT is an open‑style double‑row cylindrical roller bearing. It adopts back‑to‑back roller layout and outer‑ring lubriion groove. It bears tremendous radial load and withstands overturning shaft‑forces. Manufactured from hardened GCr15 bearing steel, it features outstanding static‑load capacity, suited for heavy‑duty gearboxes, metallurgical transmission shafts and mining‑industry machinery.
*Send inquiry to get latest factory price and technical datasheet.
Key Specifiions
| Specifiion | Value |
|---|---|
| Bearing Model | E5022NRNT |
| Bearing Type | Double‑Row Cylindrical Roller Bearing |
| Number of row | Double Row |
| Inner diameter d | 110 mm |
| Outer diameter D | 170 mm |
| Width B | 80 mm |
| Material | GCr15 Chrome Bearing Steel |
| Seal Type | Open |
| Minimum Chamfer r | 1 mm |
| Basic Dynamic Load Cr | 380000 N |
| Basic Static Load C0r | 695000 N |
| Grease Limit Speed | 900 rpm |
| Net Weight | 6.50 kg |
Main Features
- Double‑row roller construction for outstanding heavy radial‑load capacity
- Back‑to‑back internal arrangement for excellent shaft‑tilting resistance
- Outer‑ring oil groove enables easy on‑site lubricant filling
- Open‑type framework, convenient for regular inspection and maintenance
- High static load rating for equipment enduring stationary heavy loads
- Hardened GCr15 chrome‑bearing‑steel raceway for long‑term wear‑resistance
Typical Appliions
- Heavy‑duty industrial reduction gearboxes
- Metallurgical plant heavy‑duty drive shafts
- Mining crushing and bulk‑material processing machinery
- Heavy‑load belt conveyor main‑shaft assemblies
- Construction‑equipment heavy‑duty transmission parts
- Rotary industrial mixer and agitator bearing positions
*Check matched bearing models to complete your mechanical assembly.
Why Choose GQZ Bearing
- 30 years professional bearing industry experience
- ISO certified strict quality inspection
- Flexible OEM & private label customization
- 3-5 days fast delivery for stocked bearings
- Full bearing series, universal interchangeable size
- Factory direct price & reliable after-sales service
FAQ
Q1: What bearing type does E5022NRNT belong to?
A1: It is a double‑row cylindrical roller bearing with back‑to‑back roller configuration.
A1: It is a double‑row cylindrical roller bearing with back‑to‑back roller configuration.
Q2: What are the complete dimensional specifiions?
A2: Bore 110 mm, outer diameter 170 mm and overall width 80 mm.
A2: Bore 110 mm, outer diameter 170 mm and overall width 80 mm.
Q3: What loads can this double‑row roller bearing carry?
A3: It primarily bears huge radial load and resists shaft overturning force.
A3: It primarily bears huge radial load and resists shaft overturning force.
Q4: What is its limiting rotational speed under grease lubriion?
A4: The grease‑based limiting working speed reaches 900 rpm.
A4: The grease‑based limiting working speed reaches 900 rpm.
Q5: What practical function does the outer‑ring oil groove serve?
A5: Operators can inject lubriing grease directly without bearing disassembly.
A5: Operators can inject lubriing grease directly without bearing disassembly.
*Place your enquiry to check stock availability, bulk‑order discounts and long‑term after‑sales assistance.
