High Precision Tapered Roller Bearing NA48990SW Oil / Grease Lubrication

Tapered roller bearing type belongs to the separation bearing, bearing of both the inner and outer taper line groove. According to these bearings on the column number of the roller is divided into single row, double row and four row circular cone roller bearings of different structure. Single row circular cone roller bearings can bear radial load and the single direction axial load. When bearing radial load, axial force component, would create a so when need another affordable bearing axial force in the opposite direction to balanceTapered roller bearing

The low noice tapered roller bearing
The high quality tapered roller bearing
The high speed tapered roller bearing

Specification	dimensions(mm)			weight(kg)
	d	D	T
1986/1932	25.400	58.738	19.050	0.24
M84249/M84210	25.400	59.530	23.368	0.32
15578/15523	25.400	60.325	19.842	0.27
15101/15243	25.400	61.912	19.050	0.29
15116/15245	30.112	62.000	19.050	0.26
17119/17244	30.162	62.000	16.002	0.23
M86643/M86610	30.162	68.262	22.225	0.41
3187/3120	30.162	72.626	30.162	0.59
2558/2523	30.163	69.850	23.812	0.46
15120/15245	30.213	62.000	19.050	0.26
14116/14283	30.226	72.085	22.385	0.44
M86648A/M86610	30.995	64.292	21.433	0.32
08125/08231	31.750	58.738	14.684	0.16
LM67048/10	31.750	59.131	15.875	0.17
15126/15245	31.750	62.000	19.05	0.25
2580/2520	31.750	66.421	25.400	0.39
02476/02420	31.750	68.262	22.225	0.38
M88046/10	31.750	68.262	22.225	0.40
23491/23420	31.750	68.262	26.988	0.49
14125A/14276	31.750	69.012	19.845	0.34
2582/2523	31.750	69.850	23.812	0.44
3193/3120	31.750	72.626	30.162	0.57
02876/02820	31.750	73.025	22.225	0.45
2879/2820	31.750	73.025	22.225	0.46
HM88542/HM88510	31.750	73.025	29.370	0.61
HH224346/HH224310D	114.3	212.725	142.875	20.9
HH224346NA/HH224310D	114.3	212.725	142.875	21
HM926740/HM926710D	114.3	228.6	115.888	20.5
HH224349/HH224310D	114.976	212.725	142.875	20.8
M224748/M224710D	120	174.625	77.788	5.8
M224749/M224710D	120.65	174.625	77.788	5.7
795/792D	120.65	206.375	107.95	14
48286/48220D	123.825	182.562	85.725	7.4
95491/95927D	124.943	234.95	142.875	25.7
L225849/L225812D	127	169.975	58.738	3.45
48291/48992D	127	182.563	85.725	6.99
67388/67322D	127	192.85	101.6	11.1
67388/37323D	127	196.85	107.95	11.4
67388/67325D	127	200.025	101.6	11.7
