Rubber Sealed One Way Direction Bearing CSK40PP One Way Sprag Clutch Bearing
Price:
negotiation
MOQ:
1 pcs
Delivery Time:
3 working days after received your payment
Brand:
GQZ or OEM
Product Description
Rubber Sealed One Way Direction Bearing CSK40PP One Way Sprag Clutch Bearing
1. Specification:
| Metric Series | Inch series | Introduction |
| AXK | TC | Thrust needle roller and cage assemblies, single cage |
| NTB | NTA | Thrust needle roller and cage assemblies, double cage |
| AXW | Thrust needle roller bearings with centering | |
| AX | Thrust needle roller bearings with washer | |
| K811,K812,K893,K874,K894 | Thrust roller and cage assembly | |
| GS811,812,893,874,894 | Thrust race, outer surface grinding | |
| WS811,812,893,874,894 | Thrust shaft ring, the inner surface grinding | |
| LS | Thrust washers, economical, no grinding inner and outer surfaces | |
| ZS | Center washer | |
|
AS |
TWA,TWAB,TWC,TWD; | Thrust washer |
| TRA,TRB,TRC,TRD | Thrust washer |
2. Feature:
(1) One way direction
(2) has two keyway in inner ring and outer ring
(3) Rubber seals
(4) Competitive price
(5) Good qualtiy
(6) Rich stock
(7) Quick delivery
3. Bearing Picture:
4. We also supply following needle roller bearings:
| Model | Dimension (mm) | Rating Torque (Nm) |
W.G(Kg) | dimension (mm) | |||||
| ID | OD | T | H | h | d1 | D1 | |||
| CSK8 | 8 | 22 | 9 | 2.5 | 0.015 | 3 | 3 | 8.5 | 21.5 |
| CSK12 | 12 | 32 | 10 | 7.5 | 0.04 | 2 | 4 | 13.2 | 31.4 |
| CSK15 | 15 | 35 | 11 | 13.5 | 0.05 | 2 | 5 | 16.2 | 34.4 |
| CSK17 | 17 | 40 | 12 | 24.5 | 0.07 | 2 | 5 | 18.2 | 39 |
| CSK20 | 20 | 47 | 14 | 40 | 0.11 | 3 | 6 | 21.6 | 45.5 |
| CSK25 | 25 | 52 | 15 | 68 | 0.14 | 6 | 8 | 27 | 50 |
| CSK30 | 30 | 62 | 16 | 110 | 0.21 | 6 | 8 | 32 | 60 |
| CSK35 | 35 | 72 | 17 | 140 | 0.3 | 8 | 10 | 37.4 | 69.5 |
| CSK40 | 40 | 80 | 22 | 260 | 0.5 | 10 | 12 | 43.2 | 77 |
| CSK305 | 25 | 62 | 17 | 120 | 0.25 | 6 | 8 | 27 | 60 |
| CSK306 | 30 | 72 | 19 | 160 | 0.38 | 6 | 8 | 32 | 69.5 |
| CSK12-2RS | 12 | 32 | 14 | 7.5 | 0.05 | 2 | 4 | 13.2 | 31.4 |
| CSK15-2RS | 15 | 35 | 16 | 13.5 | 0.07 | 2 | 5 | 16.2 | 34.4 |
| CSK17-2RS | 17 | 40 | 17 | 24.5 | 0.09 | 2 | 5 | 18.2 | 39 |
| CSK20-2RS | 20 | 47 | 19 | 40 | 0.145 | 3 | 6 | 21.6 | 45.5 |
| CSK25-2RS | 25 | 52 | 20 | 68 | 0.175 | 6 | 8 | 27 | 50 |
| CSK30-2RS | 30 | 62 | 21 | 110 | 0.27 | 6 | 8 | 32 | 60 |
| CSK35-2RS | 35 | 72 | 22 | 140 | 0.4 | 8 | 10 | 37.4 | 69.5 |
| CSK40-2RS | 40 | 80 | 27 | 260 | 0.6 | 10 | 12 | 43.2 | 77 |
