P2.9 ORB Series 500X1000mm outdoor rental LED display 4500nits 7680hz for Stage and events

The ORB P2.9 LED display boasts a detachable 400W power supply, pin-based signal transmission, and a magnetic module design with 12 magnets per module for front-service accessibility. Its rubber-covered power connector ensures waterproof and dustproof protection. Delivering superior performance with a 7680Hz refresh rate, ≥4500nits brightness, 4000:1 contrast ratio, and 16-bit grayscale, it offers vibrant visuals in any environment. Robust corner protectors and panel feet safeguard components, making it ideal for concerts, sports events, exhibitions, and stage productions.

product features:

• Detachable Power Design: The ORB P2.9 LED display adopts a detachable power supply, with a power consumption of 400W. Signal transmission is achieved through pin connectors. This innovative design eliminates the need for wires and moving parts, simplifying installation and maintenance while ensuring stable operation.

• Magnetic Module Design: Each module is equipped with 12 powerful magnets, enabling front service accessibility. This magnetic design not only facilitates quick installation and maintenance from the front but also ensures a secure fit of the modules.
• Waterproof & Dustproof Power Connector: The power connector is designed with a rubber cover, providing reliable waterproof and dustproof protection. This feature is particularly advantageous in outdoor environments, safeguarding the display from harsh weather conditions and extending its lifespan.

Applications:

• Concerts: Deliver stunning visual effects that complement live performances, enhancing the audience's experience.
• Sports Screenings: Provide clear and vibrant displays for sports events, whether in stadiums or public viewing areas.
• Exhibitions: Showcase products and information with high-definition visuals that attract attention and engage visitors.

• Stage: Create dynamic backdrops for theatrical productions, fashion shows, and other stage events.




  Specification:




  SPECIFICATION
  Model	ORB-2.6	ORB-2.9	ORB-3.9	ORB-4.8
  Physical Pitch	2.6mm	2.97mm	3.91mm	4.81mm
  Pixel Configuration	SMD1921	SMD1921	SMD1921	SMD2727
  Pixel Density	147,456 pixels/㎡	112,896 pixels/㎡	65,536 pixels/㎡	43,264 pixels/㎡
  Module Dimensions (WXH)	250x250mm
  Panel Dimensions(WXHXD)	500x500x80mm/500x1000x80mm
  Physical Resolution of Module(WXH)	96x96px	84x84px	64x64px	52x52px
  Physical Resolution of Panel(WXH)	192x192px 192x384px	168x168px 168x336px	128x128px 128x256px	104x104px 104x208px
  Panel Material	Die-casting Aluminum
  Weight(sqm)	8kg/14kg(17.63lbs/30.86lbs)
  Processing	16bit
  Colours	281 trillion
  Avg. Power Consumption	64W/panel / 128W/panel
  Max. Power Consumption	192W/panel / 384W/panel
  Refresh Rate	3840/7680Hz
  Brightess	≥4500nits
  Horizontal Viewing Angle	160°
  Vertical Viewing Angle	140°
  Expected Lifetime	100,000Hrs
  IP Rating (Front/Rear)	IP 65/IP54
  Operation Temp/ Humidity	-10℃-60℃ /10%-60%
  Storage Temp/ Humidity	-30℃-60℃ /10%-60%
