Concert Outdoor Rental LED Display With High Color Uniformity IP65/IP54
Concert Outdoor Rental LED Display With High Color Uniformity IP65/IP54
Outdoor Rental LED Display Description:
1, Fanless design and ernergy saving
2, Steady performance and low death rate of light
3, High color uniformity and clear image can bring you a vivid audio visual effect
4, Own designing team for new products development
5, Wide visual angle, smooth surface
5. High gray scale (16 bits) with perfect real visual performance and effects
6. Available models: P3.91, P4.81, P6.25mm
7. HD show without water ripple on program broadcasting
Outdoor Rental LED Display Parameters
| SPECIFICATION | |||
| ORA-3 | ORA-4 | ORA-6 | |
| Physical Pitch | 3.91mm | 4.81mm | 6.25mm |
| Pixel Configuration | SMD2727 | SMD2727 | SMD2727 |
| Pixel Density | 65,536 pixels/sqm | 43,264 pixels/sqm | 25,600pixels/sqm |
| Module Dimensions (WXH)(mm) |
250X250 | 320X320 | 320X320 |
| Panel Dimensions(mm) | 500X500X75 /500X1000X75 | 500X500X75 /500X1000X75 | 500X500X75 /500X1000X75 |
| No. of Modules Per Panel(WXH) |
2X2 / 4X4 | 2X2 / 4X4 | 2X2 / 4X4 |
| Physical Resolution of Module(WXH) |
64X64 | 52X52 | 40X40 |
| Physical Resolution of Panel(WXH) |
104X104/104X208 | 104X104 /104X208 | 80X80 /80X160 |
| Panel Material | Die-casting Aluminum | Die-casting Aluminum | Die-casting Aluminum |
| Weight | 9/15kg/panel | 9/15kg/panel | 9/15kg/panel |
| Processing | 16bit | 16bit | 16bit |
| Colours | 281 trillion | 281 trillion | 281 trillion |
| Contrast Ratio | 2,000:1 | 2,000:1 | 2,000:1 |
| Average Power Consumption |
75/150 W/panel | 75/150 W/panel | 75/150 W/panel |
| Max Power Consumption |
225/550W/panel | 225/550W/panel | 225/550W/panel |
| Refresh Rate | >1920Hz | >1920Hz | >1920Hz |
| Brightess | ≥6,000nits | ≥6,000nits | ≥6,000nits |
| Horizontal Viewing Angle |
160° | 160° | 160° |
| Vertical Viewing Angle |
140° | 140° | 140° |
| Expected Lifetime | 100,000Hrs | 100,000Hrs | 100,000Hrs |
| Servicing | Front/Rear | Front/Rear | Front/Rear |
| IP Rationg (Front/Rear) |
IP 65/IP54 | IP 65/IP54 | IP 65/IP54 |
| Operation Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
| Storage Temp/ Humidity |
—20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% | —20℃-50℃ /10%-90% |
Outdoor Rental LED Display Application:
Stadium perimeter, telecommunications, customs, stadiums, studio, railways, airports, harbors, mobile media, Commercial advertising, stock exchange centers, bus station, shopping malls, such as banks,schools,night club, business establishments,entertainment events, etc;
