3.5 Tons Hydraulic Deck Lift Elevator , Warehouse Goods Elevator Lifts Commercial
3.5tons Warehouse Goods Hydraulic Elevator Lift Hydraulic Guide Rail Lift Platform 2 Years Warrenty:
Product Description:
Hydraulic warehouse cargo elevator provides fast, efficient, convenient and safe access to mezzanines, balconies, basements, and any levels in multistoried building. It can be installed indoor and outdoor applications.
Our products can be cuetomized:
| Model | Loading Capacity | Lifting height | Min.height | Table size | Power |
| SJG0.5-4.5 | 500kg | 4500mm | 150mm | 2000*1500mm | 2.2kw |
| SJG1.0-4.5 | 1000kg | 4500mm | 150mm | 2000*1500mm | 3kw |
| SJG2.0-4.5 | 2000kg | 4500mm | 150mm | 2000*1500mm | 3kw |
| SJG3.0-4.5 | 3000kg | 4500mm | 160mm | 2000*1500mm | 3kw |
| SJG0.5-7.5 | 500kg | 7500mm | 150mm | 1200*1200mm | 1.5kw |
| SJG1.0-7.5 | 1000kg | 7500mm | 150mm | 1800*1400mm | 2.2kw |
| SJG2.0-7.5 | 2000kg | 7500mm | 150mm | 2000*1500mm | 2.2kw |
| SJG3.0-7.5 | 3000kg | 7500mm | 160mm | 2000*1600mm | 3kw |
| SJG1.0-10.5 | 1000kg | 10500mm | 150mm | 1800*1400mm | 2.2kw |
| SJG1.0-14 | 1000kg | 1400mm | 150mm | 1800*1500mm | 2.2kw |
| SJG3.0-4.5 | 3000kg | 4500mm | 160mm | 5000*3000mm | 4kw |
Safety control of Hydraulic warehouse cargo elevator:
The Warehouse Goods Hydraulic Elevator Lift not only have all safety device of the traditional elevator, but also have the special safety system hereinafter.
1. Spillover valve, it can prevent high pressure when the machine moves up.
2. Manual emergency valve, it can go down to the nearest floor and open the door when you meet an emergency.
3. Manual pump: it can move up the nearest floor and open the door when you meet an emergency.
4. Pipe fracture valve, when the hydraulic system pipe fracture, it can cut down the channel of the oil to stop the falling.
5. Overload protection, when the goods on the platform is over the capacity, the overload protect device will work to stop the platform lifting up.
Packing:
Parts showing:
After sales:
1. User-friendly English manual for machine installation using and maintenance.
2. One year warranty for whole machine without man-made fault;
3. We will send you parts for free if there are any non-human factors problem during warranty time
4. 24-hours technical support by email, telephone or other communication online.
5. We could reply you in 2 hours after received your any questions even on weekend and holiday, engineers are available to your country if necessary.
FAQ:
1. MOQ?-one set
2. Delievery time?-usually within 15-20 working days upon receipt of payment.
3. Application field?-see product description
4. Trade term? ( FOB/CFR/CIF to your nearest seaport)
5. Working Height?-according to your need
6. Platform Size?-according to your need
7. load capacity?-according to your need
8. Demand power source?-electric or battery, per your need
9. OEM?-accepted
