CE 5T Heavy Duty Warehouse Stationary Hydraulic Scissor Lift 5M Max Lifting Height
CE 5T 5M Heavy Duty Warehouse Material Scissor Lift Hydraulic Upright Cargo Lift:
Key parameters:
|
Load weight: |
5000kgs |
|
Table size: |
8m x 3m |
|
Lift height: |
5m |
|
Structure: |
high-strength Mn steel material |
|
Control system |
1 control box, 1 control panel |
|
Power: |
380v / or 220v / or 240v / or 400v |
|
Safety device: |
explosion-proof lock valve |
|
Standard |
CE, ISO9001 |
Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the goods above platform.
3) Equipped 4 guide rails, to ensure the Warehouse Elevator Lift runs more smoothly and steadily.
4) The limit switch system helps the lift to stop at accurate position.
5) Electricity leakage protection device is equipped on, all electric components are CE certified.
6) All the warehouse elevator lift are passed 1.2 times loading test before leaving factory.
We have two types of Warehouse Scissor Lift as follows,
Application:
·The warehouse scissor lift can be used to lift cargo with different levels, suitable for cargo moving between stairs, from basement to first floor, or to second floor.
·Operation is easy. There are 2 sets control system installed on the warehouse elevator lift, 1 control box below, and 1 hand controller on safety guard rail that can be operated on work platform.
The frequent models we supplied for our clients:
|
MODEL |
LOAD CAPACITY |
PLATFORM SIZE |
LIFT HEIGHT |
PIT DEPTH |
POWER |
|
SJG0.3-2 |
0.3T |
1.5m x 1.5m |
2m |
400mm |
220V, 240V, 380V or 400V |
|
SJG0.5-3 |
0.5T |
2m x 1.8m |
3m |
500mm |
220V, 240V, 380V or 400V |
|
SJG1-4.5 |
1T |
2.1m x 1.5m |
4.5m |
650mm |
220V, 240V, 380V or 400V |
|
SJG1.5-4 |
1.5T |
2.2m x 1.6m |
4m |
600mm |
220V, 240V, 380V or 400V |
|
SJG2-6.5 |
2T |
5.2m x 2.8m |
6.5m |
800mm |
220V, 240V, 380V or 400V |
|
SJG2.5-3 |
2.5T |
5.2m x 2.6m |
3m |
750mm |
220V, 240V, 380V or 400V |
|
SJG2.5-3.5 |
2.5T |
5.2m x 2.6m |
3.5m |
800mm |
220V, 240V, 380V or 400V |
|
SJG2.5-5 |
2.5T |
5.6m x 3m |
5m |
800mm |
220V, 240V, 380V or 400V |
|
SJG3-2.5 |
3T |
5m x 2.3m |
2.5m |
750mm |
220V, 240V, 380V or 400V |
|
SJG3-3 |
3T |
5.2m x 2.6m |
3m |
800mm |
220V, 240V, 380V or 400V |
|
SJG3-3.5 |
3T |
5.6m x 2.7m |
3.5m |
800mm |
220V, 240V, 380V or 400V |
|
SJG5-10 |
5T |
4.5m x 2.5m |
10m |
1150mm |
220V, 240V, 380V or 400V |
|
SJG8-2.5 |
8T |
6.5m x 4.5m |
2.5m |
850mm |
220V, 240V, 380V or 400V |
|
SJG12-3 |
12T |
5.5m x 2.8m |
3m |
950mm |
220V, 240V, 380V or 400V |
|
SJG15-4.5 |
15T |
8m x 2.2m |
4.5m |
1150mm |
220V, 240V, 380V or 400V |
|
SJG20-5 |
20T |
6m x 3m |
5m |
1200mm |
220V, 240V, 380V or 400V |
|
The warehouse scissor lift can be customized as your detailed size. |
|||||
Factory pictures:
The workers test the 3 warehouse scissor lift for our clients from India in our factory:
The Tanzania customers came to test the warehouse scissor lift in our factory:
The products in our factory:
The customers visiting:
Our services:
1) We can design the warehouse scissor lift as per your requirement.
2) The most suitable warehouse scissor lift will be recommended to you once we get your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) 2 years warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and holiday.
Engineers are available to your country if necessary.
