Chinese Industrial Forklift Truck CPD35 / Four Wheel electric fork trucks

Price Negotiable
Price: negotiation
MOQ: 1 unit
Delivery Time: 20 working days after received L/C or your deposit
Brand: Visbull
Product Description

Chinese Industrial Forklift Truck CPD35 / Four Wheel electric fork trucks



Description:


1. Original brushless DC motor technology, with high torque, low rpm, low current, and high efficiency working.
2.120 ampere-current battery is low replacement cost.
One battery set is 3000-7000 cheaper than normal forklift.
3.10 ampere charger can bring 15-25kwh power savings than normal ones during 8 hours charging in one day.
4. Super minor turning radius 1.2 meter, operate freely in narrow space, can drive into the container or large truck directly, and load/unload cargoes flexibly.
5. Moderate lifting speed of the fork to ensure the human safety and cargo safety.
6.0.8 meter overall width makes the forklift can freely through the narrow doors, such as cold store and elevator. Particularly applicable to the refrigeration storage and supermarket.
7. Radiation protection and anti-jamming, suitable for production workshop and warehouse of the high-end electronic products.
8. Brushless motor with no need for changing the carbon brush, saving the time, effort, and money.
9. Professional sales group and service team will let you reassuring buy and safety operation, makes you feel convenient and happy.
Bettering mini electric forklift model of economical and practical, pioneer of agility and convenience.



After-sale service:

1. 6-24 months warranty policy
2. We will send spare parts replace the defective or broken parts
3. Choose the cheapest and safest shipping company to save the cost
4. Track the order until you get the goods

5. Protection of your sales area, ideas of design and all your private information



Specifications:

Model CPD35
Load capacity kg 3500
Load center mm 500
Max lifting height mm 3000
Tilting angles (forward-backward) 6°/12°
Lifting speeds(with load/without load)mm 420/260
Free lift mm 160
Max Driving seeds(with load/without load )mm 14.5
Min turning radius mm 2300
Slope-climbing gradient 10%
Formal dimension Length mm 3620
Width mm 1220
Height mm 2220
Mast height fork lowered 1995
Overhead height fork raised mm 4030
Fork size L*W*T mm 1070*125*50
Fork overhang mm 490
Wheel base mm 1500
Rear overhang mm 395
Lateral fork adjustment 245-1038
Under –clearance mm 125
Tread front mm 980
Tread rear mm 950
Battery voltage v 48
Battery capacity Ah 550
Traveling motor Kw 16.6
Lifting motor Kw 10
Steering motor Kw
Tire front 7.00-12-13PR
Tire rear 18X7-8-15PR
Total weight kg 5100
Electronic controllers GE/CURTIS/ZAPI
