RAL7035 Plastic Injection Molding Products Light Grey M22 Plastic Threaded Caps

Price Negotiable

Price: Negotiation

MOQ: Negotiation

Delivery Time: 30 days

Brand: VDL

Product Description

RAL7035 Plastic Injection Molding Products Light Grey M22 Plastic Threaded Caps

Grey cap injection molded part with threaded inside hole is made from nylon material ( PA 66 ) , there is a start gear hole in the centre of top , and inside machine threads for fixing cap on another part .

Injection molded cap part has grooves on side surface , it is easy to screw cap out or in by hand .

Application

This plastic injection molded cap part is designed for communication device .

Material

Plastic injection molded cap part is made from Nylon with grade 66 , RAL 7035 color .

Specification

Outer diameter	25
Thread diameter	M22
Height	28
Start hole diameter	12
Threaded legnth	12

Features

1 , Wear resistance

2 , Good self-lubricant

3 , High mechanical property

4 , Resistant high temperature

Normally , the part can be operated smoothly at temperature 150℃ and thermal deformed temperature is up to 250℃ when parts with glass fiber .

5 , Perfect elongation

Elongation at break is 2.2% according to ISO 527 testing method .

6 , Corrosion resistance

7 , Good insulation

Specific volume resistance is 1.83×1015 and resistance to high breakdown voltage support part to be good insulated .

8 , Resistant impact

60 – 80 KJ/M2 normally .

9 , Resistant fire

Generally , the fire resistance is UL94V-2 and UL64V-0 for special parts .

10 , Resistance to low temperature

Parts can be workable at -30℃

Mechanical Property

Tensile strength MPa	60～80
Elongation at break %	2.2
Bending strength MPa	100～120
Modulus of elasticity for bending MPa	2000 ～3000
Notched Impact Strength(J/m)	60～100
HR hardness	118

Electrical Performance

Dielectric constant	1.63
Arc resistance sec	130～140
Specific volume resistance Ω·cm	1.83×1015
Dissipation factor	100～400
Dielectric strength(kV/mm)	20～30
