M6 Hex Socket Truss Head Titanium Screw Fastener for Automotive Spare Parts
M6 Hex Socket Truss Head Titanium Screw Fastener for Automotive Spare Parts
Hex socket titanium screws are made from alloy titanium TC 4 with golden oxide finish , full threads and truss head design . Titanium screw as one of automotive fasteners , it is more good than other materials fasteners on physical performance .
Material
Titanium screws are made from Ti-6Al-4V ( TC4 )
Specification
| Thread diameter | M5 |
| Thread length | 25 |
| Head diameter | 9.5 |
| Head height | 4.5 |
| Head drive | Hex |
More specifications
| d1 | d2 | K | S | t |
| 3 | 5.5 | 1.6 | 2 | 1.35 |
| 4 | 7.5 | 2.1 | 2.5 | 1.5 |
| 5 | 9.5 | 2.7 | 3 | 2.2 |
| 6 | 10.5 | 3.2 | 4 | 2.4 |
| 8 | 14 | 4.3 | 5 | 3.15 |
| 10 | 18 | 5.3 | 6 | 3.8 |
Standard
Titanium screws for automotive fasteners are normally customized according to applications .
Finish
Oxide golden
Physical Performance
| Tensile strength Mpa | 950 |
| Yeild strength Mpa | 750 |
| Hardness HV | 350 |
| Density g/cm3 | 4.5 |
| Elongation % | 35 |
Product characteristics
1 . Perfect corrosion resistance
Titanium screws are more stronger than stainless steel on anti-rust , it is capable of strong acid and alkalescent conditions .
2 . Harden material
Hardness for titanium screws up to HV350 .
3 . Resistant high and low temperature
Titanium screws can be worked from -250 to 500 degree .
4 . No burrs or scratch and bright surface
5 . Screws can be recyclable .
6 . Not easy to be broken
7 . Not easy to be conducted
8 . High tensile strength with light weight
Alloy titanium screws can be up to 1200 Mpa on tensile strength but density is only 4.5 g/cm3 .
Installation
1 . Operated by a hex key or wrench .
2 . Do not break threads for smooth installation .
3 . Make sure screws are located exactly to threaded hole centre of objects .
4 . Do not put over torque on Hi-low threads screws .
5 . Not suitable for welding .
Application
Titanium screws are widely used to automotive industry , and aviation , precise equippments and other industrial areas .
