6.38mm - 40.3mm CE and ISO9001 Curtain Wall Tempered Laminated Glass For Home
CE ／ ISO9001 Curtain Wall Tempered Laminated Glass Panels Curved for building
- wo layers or more of glass "sandwiched" together with a PVB interlayer, laminated glass is the one glass that reconciles the aesthetic benefits of glass with a genuine concern for safety; offering superior protection against glass breakage, as well as harmful solar rays and hazardous noise levels.
- Due to the adhesive properties of the PVB, Rider takes careful precautions to prevent unwanted particles from attaching to the PVB during the adhesion process.
- Tempered Laminated Glass has double safety assurance, one is by glass laminating, the other one is on behalf of glass tempering.
Laminated Glass Assembly According to Safety Requirement
| REQUIREMENT | BENEFIT |
GLASS ASSEMBLY
|
| Solar control | Energy saving | 2ply+1PVB interlayer |
| UV elimination | ||
| Sound control | Noise reduction | 2ply+1PVB interlayer |
| Safety | Lowest injury risk | 2ply+2PVB interlayers |
| Anti-bandit protection | 2ply+4-6PVB interlayers | |
| Security | Forced entry protection | 3ply+4PVB interlayers |
| Bullet proof | Decide case by case, at least | |
| Blast resistant | 4ply+multi PVB interlayers |
BENEFITS
- Holds together when shattered. The PVB interlayer keeps the glass bonded, even when broken, resulting in a characteristic spider web cracking pattern across the glass.
- Cyclone resistant
- Superior UV blockage
- Excellent sound damping properties
- Low visible distortion
Tempered glass production process
1. Cutting : cutting the annealing glass to the actual needs of shape.
2. Glass edging: Edging machine to mill the four edges to prevent frund when steeling,while
maintaining the beautiful appearance.
3. Drilling hole:If need to drilling hole using drilling machine.
4. Washing dry:cleaning the glass with washing maching.
5. Tempered glass:Tempered glass is produced by heating annealed glass in a furnace to 700°,
then the glass is rapidly cooled with jets of cold air to 40°,through the procedures, the original
glass is formed of tempered glass.
