CE Certified High Temperature Oven

1. Model : RHD-45

2. Dimensions

   Internal Dimension (W×H×D):450×400×400 (mm)

   External Dimension(W×H×D):650×900×550 (mm)

3. Temperature:RT ~ 200℃  (Temp.&Time Setting freely, automatic timing when reach the preset temp., and automatic stop temperature when time’s up).

Temp. Control Accuracy: ±0.5℃

Temp.Distribution Uniformity: ±2℃

Temp.Analytic Accuracy:0.1℃

Temp. Rising Speed: From RT~200℃,approx 35Min

4. Material of Construction:

   (1) Interior material is SUS#304 stainless steel

   (2) Exterior material is paint coated steel plate

   (3) Insulation Material of imported fire-proof rock wool

   (4) Heating Medium: electric heating tube

5. Control System

(1) P.I.D microcomputer automatic calculate temperature controller, PV/SV display at the same time, set by press key.;

(2) 220V/380V Solid state relay temperature output;

(3) Current Controller : SSR no contact relay

6. Air circulating System:

(1) Forced horizontal air circulation system;

(2) Temperature resistant special motor with long axis, and power 1/2 HP 50HZ

(3) Built-in adjustable wind guide plate.

7. Power: AC220V, One Phase Three Lines

8. Warranty: One year free warranty under normal use(Except natural disaster or man-made damage)long-life maintenance.

P.S. : The operating environment of the machine should be under Room Temperature  and with good ventilation. We strongly suggest to install air conditioner in the working area.
