Simulate Xenon Lamp Light Fastness Climate UV Aging Test Chamber
Simulate Xenon Lamp Light Fastness Tester Xenon Climate Aging Test Chamber
Corresponding standard:
- GB12831-86 Vulcanized rubber artificial climate (xenon lamp) Aging Test Method
- GB/T1644.2-1999Plastics laboratory light exposure test method
- GB/T8427-89 textile color fastness test, resistance to artificial light fastness xenon arc
- GB/T8430-98 textile color fastness test, resistance to artificial light fastness xenon arc
- GB/T1865-97 Paints, varnishes, artificial weather aging and artificial radiation exposure
- GB/T16991-97 textile color fastness test,
- GB/T5137.3-96 simulated climate test method of resistant to radiation, heat, humidity, burning
- GB/T16259-96 color building materials, artificial climate accelerated aging test method.
- GB/T2423.24-95 Electronic and Electrical Products Environmental Testing Part II: test method, testing SQ: Simulation of solar radiation on the ground
Xenon color fastness tester adopts the xenon arc lamp that can simulate full sunlight spectrum to reproduce destructive light waves existing in different environments so as to provide the corresponding environment simulation and acceleration test for scientific research, product development and quality control. It is approved by many OEMs in the automotive, paints and coatings, and plastics industries as the exclusive platform to deliver accurate, and repeatable results for predicting service life.
Simulate Xenon Lamp Light Fastness Tester Xenon Climate Aging Test Chamber Technical Perameters
|
Model |
XL - 1000 |
|||||
|
Internal Dimension |
900x900x900 |
|||||
|
External Dimension |
1500x2000x1400 |
|||||
|
Tube Using Life (H) |
1500 |
|||||
|
Tube Power |
1KW/6KW |
|||||
|
Illumination intensity |
340nm |
Full spectrum |
||||
|
Lighting Filter Type |
Inner filter |
|
Quartz |
|||
|
Outer filter |
Quartz |
|||||
|
Simulated Test Status |
|
|
Test samples: Explore under outer space |
|||
|
Cooling System |
Water cooling |
|||||
|
Temperature Control Range of the Test Cabinet |
Black panel temperature : BPT 40~120°C(±3°C) |
|||||
|
Black standard temperature : BST 38~120°C(±3°C) |
||||||
|
Humidity Control Range of the Test Cabinet |
Humidity when lighting:20%R.H.~75%R.H. (± 5%R.H.) |
|||||
|
Humidity when dark :60%R.H.~95%R.H. (± 5%R.H.) |
||||||
|
Rotating Speed of the Samples |
1~5 adjustable |
|||||
|
Diameter of Sample Shelf(mm) |
500±50 |
|||||
|
Sunlight Exposure Cycle |
0.01~999 hours 59mins |
|||||
|
Raining Period / Time |
Raining Period:1~240mins,discontinuous-type, adjustable |
|||||
|
Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa |
||||||
|
Spray Water Flow (L/min) |
1~2.4 |
|||||
|
Explore Area(cm2) |
7500 |
|||||
|
Power |
AC 380V, 50/60HZ , 3Φ 5 Lines |
|||||
