Plastic Temperature Aging Test Oven 270L 5℃/Min Heating Rate
5℃/Min Heating Rate Plastic Testing Machine Temperature Aging Test Oven
|
Model |
RHD - 45 |
RHD - 60 |
RHD - 90 |
RHD - 120 |
|
Internal Dimension W×H×D(mm ) |
450×400×400 |
500×600×500 |
600×900×500 |
800×1200×700 |
|
External Dimension W×H×D(mm ) |
650×900×550 |
700×1200×650 |
850× 1600×700 |
1200× 1680×900 |
|
Interior and Exterior Material |
Interior material is SUS 304# stainless steel, exterior is stainless steel or SEE cold-rolled steel with paint coated. |
|||
|
Temperature Range |
R.T. to 200; (300 to 500°C is optional) |
|||
|
Indication Resolution/ Distribution Uniformity of Temperature |
0.1°C/±2.0°C;( When temperature is 100°C) |
|||
|
Control Accuracy of Temperature |
±0.5°C; |
|||
|
Temperature Rising Velocity |
Temperature rising velocity: from R.T. to 200°C,needs approx. 35mins |
|||
|
Control Method |
Micro PID+SSR+Timer |
|||
|
Storage Shelf |
Two layers |
|||
|
Viewing Window |
When temperature is RT to 200°C ,with viewing widow When temperature is 200°C to 500°C ,without viewing widow |
|||
|
Power |
AC 220V 50/60HZ ; AC 380V 50/60HZ |
|||
 |
 |
 |
 |
Freestanding electric oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing . It supplys precision temperature controllter with high stability of platinum resistance to temperature that makes temperature well-distribution.
Aging test oven Features
1.Outside SECC steel, fine powder coating treatment; Inner SUS#304 stainless steel.
2.Use new high temperature resistant long shaft motor
3 Turbine fan.
4.Silicone forced tight
5.Over temperature protection, super load automatic power system.
6.Circulation system: air force level cycle.
7. Heating system:PID+S.S.R.
8.The thermostat: PID microcomputer control, automatic constant temperature, temperature quickly compensation function
9.Timer: temperature to time, when the power failure alarm indication.
10.According to customer demand matching glass window can be customized according to customer specifications specified.
Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.
