Lab Sum Simulation Acceleratled Xenon Lamp Aging Testing Chamber / Laboratory Oven
Lab Sum Simulation Acceleratled Xenon Lamp Aging Testing Chamber / Laboratory Oven
Main product including:
Environmental chambers, temperature (humidity) chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,Altitude chamber,vibration test system, mechanical shock tester,environmental combined vibration chamber,etc
Main technical dates about Xenon chamber :
|
Model |
XU - 1000 |
|||||
|
Internal Dimension |
900x900x900 |
|||||
|
External Dimension |
1500x2000x1400 |
|||||
|
Tube Using Life (H) |
1500 |
|||||
|
Tube Power |
1KW/6KW |
|||||
|
Illumination intensity |
340nm |
Full spectrum |
||||
|
Lighting Filter Type |
Inner filter |
|
Quartz |
|||
|
Outer filter |
Quartz |
|||||
|
Simulated Test Status |
|
|
Test samples: |
|||
|
Cooling System |
Water cooling |
|||||
|
Temperature Control |
Black panel temperature : BPT 40~120°C(±3°C) |
|||||
|
Black standard temperature : BST 38~120°C(±3°C) |
||||||
|
Humidity Control |
Humidity when lighting:20%R.H.~75%R.H. (± 5%R.H.) |
|||||
|
Humidity when dark :60%R.H.~95%R.H. (± 5%R.H.) |
||||||
|
Rotating Speed |
1~5 adjustable |
|||||
|
Diameter of |
500±50 |
|||||
|
Sunlight Exposure |
0.01~999 hours 59mins |
|||||
|
Raining Period |
Raining Period:1~240mins,discontinuous-type, adjustable |
|||||
|
Raining Time:1~9999mins, adjustable, water spray pressure 70~130Kpa |
||||||
|
Spray Water Flow (L/min) |
1~2.4 |
|||||
|
Explore Area(cm2) |
7500 |
|||||
|
Power |
AC 380V, 50/60HZ , 3Φ 5 Lines |
|||||
Features about xenon test chamber:
1.ASLi Brand xenon lamp weather resistance test chamber withadvanced design technology and concept.
2. ASLi Brand xenon lamp weather resistance test chamber with excellent technology of producing and outstanding system of quality management.
3. ASLi Brand xenon lamp weather resistance test chamber can be the most realistic simulated solar spectrum.
including ultraviolet, visible and infrared.
4. ASLi Brand xenon lamp weather resistance test chamber tested in the range of the full spectrum, necessary for most textile sun and color fastness test.
5. ASLi Brand xenon lamp weather resistance test chamber can determine the color fastness and aging to sunlight, weather resistance, etc.
ASLi main products of xenon arc testing:
Established in 1988, ASLi (China) Test Equipment Co., Ltd is specialized in manufacturing a variety of quality inspection instruments, testing equipments and other high-tech products .
If you have any question about the xenon arc chamber, please contact with us ,thank you.
