PID Control High Temperature Ovens , 300C Accelerated Aging Test Chamber
300C Accelerated Aging Test Chamber/High Temperature Heating Oven for Sale
Accelerated Aging Test Chamber/High Temperature Heating Oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing . It supplys precision temperature controllter with high stability of platinum resistance to temperature that makes temperature well-distribution.
|
Name
|
High Temperature Heating Oven
|
||
|
Model
|
RHD - 45
|
RHD - 60
|
RHD - 90
|
|
Internal Dimension W×H×D(mm )
|
450×400×400
|
500×600×500
|
600×900×500
|
|
External Dimension W×H×D(mm )
|
650×900×550
|
700×1200×650
|
850× 1600×700
|
|
Interior and Exterior Material
|
Interior material is SUS 304# stainless steel,exterior is stainless steel or SEE cold-rolled steel with paint coated.
|
||
|
Temperature Range
|
R.T. to 200; (300 to 500℃ is optional)
|
||
|
Indication Resolution/ Distribution Uniformity of Temperature
|
0.1℃/±2.0℃;( When temperature is 100℃)
|
||
|
Control Accuracy of Temperature
|
±0.5℃
|
||
|
Temperature Rising Velocity
|
Temperature rising velocity: from R.T. to 200℃,needs approx. 35mins
|
||
|
Control Method
|
Micro PID+SSR+Timer
|
||
|
Storage Shelf
|
Two layers
|
||
Specifications
1. Outside SECC steel, fine powder coating treatment; Inner SUS#304 stainless steel.
2. Use new high temperature resistant long shaft motor
3 Turbine fan.
4. Silicone forced tight.
5. Overtemperature protection, super load automatic power system.
6. Circulation system: air force level cycle.
7. Heating system:PID+S.S.R.
8.The thermostat: PID microcomputer control, automatic constant temperature, temperature quickly compensation function
9. Timer: temperature to time, when the power failure alarm indication.
10.According to customer demand matching glass window can be customized according to customer specifications specified.
300C Accelerated Aging Test Chamber/High Temperature Heating Oven for Sale, please feel free to contact me if any needs.
