Light Resistant Aging Testing Instrument UV Aging Chamber , UV Accelerated Aging Tester
GB/T16422,GB/T5170.9 Accelerated Aging Instrument Plastic UV Aging Test Chamber
| Model | UV-290 | |
| Internal Dimension WxHxD (mm) | 1150x500x500 | |
| External Dimension WxHxD (mm) | 1400x1600x750 | |
| Applicable Standard | GB/T16422,GB/T5170.9 | |
| Temperature Range | R.T.+15°C~+70°C | |
| Temperature Fluctuation | ±0.5°C | |
| Humidity Range | ≥95%R.H. | |
| Environmental Temperature for Use | +5°C~+35°C | |
| Test Light Source | UVA,UVB UV light | |
| Wave Length of Test light Source (nm) | 280~400 | |
| Center Distance between Sample and Tube (mm) | 50±2 | |
| Center Distance Between Tubes (mm) | 75±2 | |
| Material of Internal Case | Stainless steel with sanding polish | |
| Material of External Case | Stainless steel with sanding polish or painting coated | |
| Heating and Humidifier | Electric-heat type steam generator ,heating and humidification | |
| Safety System | Operation Interface | Digital smarts touch key input (Programmable) |
| Running Mode | Program/constant running type | |
| Input | Black panel thermometer.PT-100 Sensor | |
| Standard Configuration | 1 pc Stainless steel shelves | |
| Safety Configuration | Protection of electric leakage, power outage when over-load, over-temperature protection, water short storage, ground lead protection | |
| Power | AC220V 1 phase 3 lines, 50HZ | |
GB/T16422,GB/T5170.9 Accelerated Aging Instrument Plastic UV Aging Test Chamber can simulate the sun, rain and dew to damage the material, UV machine using UV lamp simulate the effect of sunlight, cold rain and dew. Being tested materials are placed in a certain environment which the light and moisture are alternating. The materials are tested for several days or weeks, you can know the damage of material at outside for several months or several years, Damage types include: bleaching, discoloration, loss of light, powder, crack, turbidity, bubble-based, embrittlement, strength decline and oxidation.
Corresponding standard
Accord with ASTMG53-77/ GB/GJB/MIL/ASTM/CNS/IEC/JIS/AATCC/DIN/Fed Test/BS/SAE
Applicable industries
GB/T16422,GB/T5170.9 Accelerated Aging Instrument Plastic UV Aging Test Chamber is widely used in paint, resins, plastics, printing and packaging, aluminum, adhesives, auto, cosmetics, metals, electronics, electroplating, medicine, etc..
2.Shipment with professional documents.
3.Packing as your request, with photo before shipment.
4.Reply within 48 hours and provide solution within 3 working days
5.Professional after-service from our engineers.
6.Warranty period 12 months
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 50% T/T in advance ,balance before shipment.
