8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks
8 Wires / 5 wires Electric Bolt Lock Zinc Alloy Fail Secure Electronic Bolt Locks
This door lock is special in design with durable material . It can protect your home or business shops . Low operational and standby current . It's especially suitable for glass doors . Great choice for you .
Specification:
| Fail Safe: | unlock when power off |
| Lock body size: | 157.5Lx31Wx40H(mm) |
| Face plate size: | 200Lx34Wx3.4H(mm) |
| Blot out plate size: | 210Lx42Wx0.8H(mm) |
| Magnet bracket: | 90Lx24Wx3H(mm) |
| Lock pin: | 15.5mmDIA,stainless steel out throw15mm |
| Voltage: | DC12V |
| Current: |
Start: 0.85A Standby: 0.09A |
| Holding force | 1000kg |
| Solenoid: | Continuous duty |
| Auto relock Timer jumper | adjustable (0/3/6/9S) |
| Surface Temp: | ≦20℃ |
| Induction Distance | 8mm |
| Operating temp: | -10~+25℃(14-131F) |
| Operating Humidity: | 0~90%(non-condensing) |
| Face place material: | High Aluminum, Carrulous Line Finished |
| Weight: | 0.9kg |
| Standard Packing: | 10pcs. |
| Carton size: | 53Lx30Wx14H(cm) |
Feature
▶Low Temperature, safe & Durable
▶Low Power, Environmental Protection
▶MOV Provides Reverse Current Protection
▶Superior Strength Aluminum Alloy, Solid Stainless Steel Bolt
▶Request-to-open, Auto-relock if no Action within 5 sec
▶CE Certificate by European Union, MA China Public Security office
Quality Guarantee :
Warranty Service will be honored if the damage is not caused by human, JUNSON Provides 2 years
warranty for relative products. On the contrary, JUNSON will charge extra if repair. More information,
please browse our service center.
We offer many Electronic lock, like: Magnetic door lock, Electric deadbolt lock, Electric strike, Electric
bolt lock, Electronic lock.
