Economical Heart Shaped Disposable Paper Plates Making Machines Long Lasting Universal
Economical Heart Shaped Disposable Paper Plates Making Machines Long Lasting Universal
Quick Details
| Paper Plate Size | 3-11 inch (mould exchangable), Bigger or specially available |
| Productivity | 70-100 Pcs/min |
| Warranty | 1 years |
| Usage | Round Plate or other shape plate |
| after-sales service | Engineers available to service machinery overseas |
Model ZDJ-400K Medium-speed Automatic Paper Plate Forming Machine was developed and researched in order to meet the market requirement. It has integrated the pneumatic and the mechanic technologies, which makes it has the functions of faster working speed, higher safety-performance, safer operation and easier maintenance. Model ZDJ-400 medium-speed paper plate machine adopts high efficient pressurizing air cylinder, so that the Max. Pressure can reach to 5 Ton. Compared with the oil pressure one, it has the advantages of high speed, environment protection and humanism design.
It is widely applied to make paper plate (or aluminum foil laminated paper plate) in round (rectangle, square, circular, or irregular) shape.
Specification
| Paper Plate Size | 3-11 inch (mold exchangeable) |
| Paper Material | 180-500g/m2 Paper/paperboard, aluminum foil coated paper, one side PE coated paper or other |
| Speed of Production | 70-100 piece/minute (total two working stations) |
| Power Source | 220V 50Hz |
| Total Power | 3KW |
| Total Weight | 500KG |
| Package Size | 1480×1150×2050 mm |
| Working Air Source |
Air pressure:0.8Mpa, Air Out-put: 1.5m³/minute |
Advantage
| Mold Installment | The machine is with two free molds installed |
| Air Cylinder | Our machine use much more stroner air cylinder than others, which makes the plate pressing more exactly(we use Taiwan cylinder) |
| Paper Clamping Manipulator | The paper plate machine is using the automatic paper clamping manipulater system, which save a lot of time and labor costs |
| Free Spare Parts |
one year guarantee,will give spare parts with machine while packing (enough for 2 years using) with one year,all parts given for free, after that we need charges and delivery cost |
Loading Machine
