High Frame Rate And Clear Images , Cooled HgCdTe FPA Thermal Imaging Module For Security / Surveillance
MWIR Cooled Thermal Imaging Camera Module For Security And Surveillance
Description
Medium-wave Cooled HgCdTe FPA Thermal Infrared Imaging Module is a cooled MCT thermal imaging module operating in 3.7~4.8um (B mode: 7.7~11um) spectral band, which provides OEMs with an extremely compact and high performance solution. It applies to complete thermal camera development and system integration for the research institutes and enterprises.
Features
- FPGA intelligent image processing platform providing high frame rate and clear images
- A variety of control interface and image output interface for easy integration
- Triple FOV, dual FOV, fixed lens and lens-less configuration available
- Compact structure, small size and light weight
Functions
- WH/BH polarity switch
-
Manual/automatic image gain / brightness adjustment
-
Image enhancement / smoothing / sharpening, sky/ground pattern algorithm
-
Automatic focus, FOV switch, continuous zooming
-
Manual background / shutter calibration
Technical Specifications
| Detector | |
| Detector material | Cooled MCT FPA |
| Pixels | 320x256 |
| Pitch | 30µ mx30µ m |
| Spectral band | (A mode) 3.7~4.8µm (B mode) 7.7~11µm |
| NETD | < 15mK (F/2) |
| Cooling type | Stirling-cycle, Cooling temperature: < 100K Cooldown time: < 6min@20° C; < 8min@50° C |
| Fill factor | 90% |
| Optical Parameters | |
| Focus length (optional) | 300mm/75mm, 240mm/60mm, 600mm/150mm/22mm |
| FOV | 1.8°x1.4°/ 7.3°x5.8° ; 2.3°x1.8°/9.1°x7.3°; 0.92°x0.73°/4°x3.2°/24.6°x19.8° |
| Image presentation | |
| Video output | Analog PAL/NTSC (Digital: Cameralink) |
| Integral time | programmable |
| Frame rate | 25, 50Hz, 100Hz, 200Hz |
| Electric zoom | x2, x4 |
| Polarity | BH & WH |
| Gain adjustment | Auto/Manual |
| Power system | |
| Power supply | DC24V (DC8V~42V) |
| Power consumption | < 20W (cooling), <14W (steady operation) |
| Operating temperature | -40° C~60° C |
| Storage temperature | -40° C~60° C |
| Command & Control | |
| Communication Interface | RS232 / RS422 |
| Physical parameters | |
| Weight | < 810g (lensless); <10.5kg (300mm/75mm); <9.8(240mm/60mm) |
