20m 30m 40m 50m Large Event Tents For Trade Shows And Exhibitions
20m 30m 40m 50m Large Frame Tents For Trade Shows And Exhibitions
When you need more space, the tent can be designed as a two-story tent or triple-decker tent, so you will have two or three floors of use area, arranging the space suitably to make the event more colorful, and the wall can be designed with glass walls to make the event more gorgeous and fashionable.
The height of the tent is not fixed. Like some large events, when you need to place some professional equipment for shooting and stage layout, the common tent height will not meet the current needs, we can provide you with customized services, according to the actual situation of the event, and provide you with different height tent buildings. Hosting events at different heights and event tents will bring clients different feelings, and the space will be more spacious and comfortable.
| Dimension | Clear Span | Eave Height | Ridge Height | Bay Distance |
| BT 18 | 18m | 4m | 7.06m | 5m |
| BT 20 | 20m | 4m | 7.1m | 5m |
| BT 25 | 25m | 4m | 7.25m | 5m |
| EBT 30 | 30m | 4m | 8.9m | 5m |
| TH 40 | 40m | 4m | 10.4m | 5m |
| LH 50 | 50m | 5m | 13m | 5m |
| HH 60 | 60m | 5m | 14.6m | 5m |
| Main Profile | 204x120x4mm, 256x121x5mm, 300x120x5mm... | |||
Specifications & Features
- Framework: hard-pressed extruded aluminum 6061/T6(15HW) which can last over 20 years.
- Roof Cover: high-quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear-resistant, self-cleaning, etc.
- Connector: strong hot-dip galvanized steel
- Allowed Temperature Condition: -30 degrees Celsius~+70 degree Celsius
- Wind Loading: max. 100km/h (can be reinforced)
- Snow Loading: 30kg/sqm
- Easy to be assembled and dismantled, moved from place to place.
- No pole inside, and 100% available interior space.
Optional Accessories
- Windows: transparent PVC fabric, glass windows...
- Roof Shape: regular A shape, dome roof, polygonal, curved roof...
- Doors: PVC sliding doors, double-wing glass doors...
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall...
- Fixing Tools: steel anchors, weight plate, expandable bolts...
- Rain Gutters: inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: printing, lighting, air conditioning, sports flooring, installation tools, etc.
Packing
- Aluminum frame packed in membrane film
- Hardware packed in a solid carton box
- Roof and sidewall in a self-made PVC carry bag
- Tailor-made packing is available
