Big Tent BTA 10m-25m
The clear span of the Big Tent-BTA series is from 10m to 25m and the main profile size is 204x110x4mm. Big Tent-BTA series are modular structures and can be increased or decreased in the bay distance of 5m according to the clients’ requirements. The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6). The PVC covers use PVC-coated polyester textile and flame retardance which is based on the European standard DIN 4102B1, M2. The big tent-BTA series can resist up to 100km/hr wind loading.
There are also many different styles and shapes of Big Tent- BTA series like a square, hexagonal, octagonal, decagonal, dodecagonal, and double decker. All clear span big tent structures are available with a complete range of accessories. These accessories are sidewalls with clear windows, ground anchors, weight plate, lining, glass wall system, and ABS hard wall system. You can use Big Tent-BTA series for both temporary and permanent solutions.

Size Available

Optional Accessories

• Covers: colourful cover, transparent cover, inflatable roof cover
• Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
• Wooden Flooring System: VIP cassette flooring, simple cassette flooring
• Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
• Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
• Fixing Methods: ground anchors, weight plate, expandable bolts
• Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
• Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.

Tent Type

System Features:

1)Four-channel aluminum frame

2) Galvanized steel connection pieces

3) Bar tensioning roof system

4) Kedered fabric system

5) Easy assmble and dismantle, no need big crane for installation

6) Less total volume, easy transport and storage

7) High quality aluminum inset connector
