50x60m Large Aluminium Movable Polygon Marquee for Exhibition and Wedding Party
Price:
USD60-70/m²
MOQ:
100m²
Delivery Time:
30-40days after payment
Brand:
Liri - Polygon Tent
Product Description
50x60m Large Aluminium Movable Polygon Marquee for Exhibition and Wedding Party
- Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
- Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
- Connector: strong hot-dip galvanized steel
- Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
- Wind load: max. 100km/h (can be reinforced)
- Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
- Easy to be assembled and dismantled, movable.
- No pole inside, 100% available interior space.
Company Information
Liri Tent Technology (Zhuhai) Co., Ltd. was established in 1997. Our company is the first professional manufacturer who introduced European advanced tents technology into our own design. Our main products include Modular Aluminium Alloy Structure Tents, Clear Span Tent Structure and Aluminium Alloy Square Pagoda & Summer Gazebo.
Liri PG Series:
| Type | Span Width | Bay Distance | Eave Height | Ridge Height | Main Profile |
| PG | 10m/32.8' | 5m/16.4' | 4m | 7.16m | 204x120x4mm(4-channel) |
| PG | 12m/39.4' | 5m/16.4' | 4m | 7.4m | 204x120x4mm(4-channel) |
| PG | 15m/49.2' | 5m/16.4' | 4m | 8.75m | 204x120x4mm(4-channel) |
| PG | 18m/59' | 5m/16.4' | 4m | 9.15m | 204x120x4mm(4-channel) |
| PG | 20m/65.6' | 5m/16.4' | 4m | 9.42m | 204x120x4mm(4-channel) |
| PG | 25m/82' | 5m/16.4' | 4m | 11.72m | 256x121x5mm(4-channel) |
| PG | 30m/98.4' | 5m/16.4' | 4m | 13.2m | 256x121x5mm(4-channel) |
| PG | 40m/131.2' | 5m/16.4' | 4m | 15.6m | 300x120x5mm(4-channel) |
| PG | 50m/164' | 5m/16.4' | 4m | 16m | 400x120x7mm(4-channel) |
| PG | 60m/197' | 5m/16.4' | 4m | 18m | 400x120x7mm(4-channel) |
| The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size is available. | |||||
Accessories of Our Tents
- Covers: colourful cover, transparent cover, inflatable roof cover
- Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
- Wooden Flooring System: VIP cassette flooring, simple cassette flooring
- Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
- Fixing Methods: ground anchors, weight plate, expandable bolts
- Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
Liri Tent series
Tent Roof Type |
Span Width | Bay Distance | Eave Height |
| "A" Shape | 3m~60m | 3m/5m | 2.6m/3m/3.3m/3.88m/4.2m/5m/5.2m |
| Domelike | 3m~40m | 3m/5m | 2.6m/3m/3.23m/3.88m/3.92m |
| High Peak | 3m~10m | 3m/4m/5m/6m/8m/10m | 2.5m/2.6m |
| Curve Shape | 15m~40m | 5m | 3.87m/3.89m |
| Polygon | 10m~60m | 5m | 4m |
| Cube Structure | 10m~30m | 5m | 5m |
