60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Temporary Large Outdoor Exhibition Tents For Temporary Event , Competition
Applications:
It is widely use for the exhibitions, brand launches, theater, concert party, and other large -scale activities. Different color and transparent cover are available, what's more, inkjet and CNC sculpture can be used to make a custom unique fabric, providing a satisfactory solution for each customer.
| Dimension | Diameter | Ceiling Height | Floor Area | Vloume |
| Dia 40 | 40m | 15m | 1256m² | 11191m³ |
| Dia 50 | 50m | 20m | 1962.5m² | 23823m³ |
| Dia 60 | 60m | 25m | 2826² | 43524m³ |
| Length | No limitation | |||
| Main Structure Profile | 300*120*5m | |||
Description:
The big tent series size from 25-40 m , it can use for different kinds of events , warehouse , and more. This series of tent can fix with full line accessories .
- If it is concrete ground , pls use the expandable bolts
- If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
- If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
- If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm
Optional Accessories
- Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
- Wooden Flooring System: VIP cassette flooring, simple cassette flooring
- Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
- Fixing Methods: ground anchors, weight plate, expandable bolts
- Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
- Adjustable flooring system, can fix on the uneven land
Structure
Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
Superiority of tents
1 Sizes can be customized
2 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
3 No pole inside, 100% room is available
4 Trouble-free and easy transportation, erection, dismantling, storage
5 Wind loading up from 80 to 100 km per hour
6 Multifunctional, widely used for different request
Life Span:
For the structure of the tent, it is strong enough for permanent or semi - permanent. The frame is using the 6061/ T6 aluminum frame, and it can use for about 20-25 years. If for the pvc roof cover, it can use for about 8 - 10 years.
