50000 Square Meter Outdoor Exhibition Tents For Movable Big Fair
50000 Square Meter Temporary Large Outdoor Exhibition Tents For Movable Big Temporary Fair
Applications:
It is widely use for the outdoor events , rental , wedding , party , exhibition ,concerts and son on . Based on the multi - functional purpose , people just need to change the different decoration will be ok.
| Dimension | Clear Span | Eave Height | Ridge Height | Bay Distance |
| TH 25m | 25m | 4m | 7.88m | 5m |
| TH 30m | 30m | 4m | 8.8m | 5m |
| TH 40m | 40m | 4m | 10.4m | 5m |
| Length | No limitation | |||
| Main Structure Profile | 300*120*5m | |||
Description:
The big tent series size from 25-40 m , it can use for different kinds of events , warehouse , and more. This series of tent can fix with full line accessories .
Optional Accessories
- Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
- Wooden Flooring System: VIP cassette flooring, simple cassette flooring
- Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
- Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
- Fixing Methods: ground anchors, weight plate, expandable bolts
- Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
- Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
- Adjustable flooring system, can fix on the uneven land
- If it is concrete ground , pls use the expandable bolts
- If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
- If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
- If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm
Structure
Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.
Life Span:
For the structure of the tent, it is strong enough for permanent or semi - permanent. The frame is using the 6061/ T6 aluminum frame, and it can use for about 20-25 years. If for the pvc roof cover, it can use for about 8 - 10 years.
Superiority of tents
1 Sizes can be customized
2 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
3 No pole inside, 100% room is available
4 Trouble-free and easy transportation, erection, dismantling, storage
5 Wind loading up from 80 to 100 km per hour
6 Multifunctional, widely used for different request
