Flame Retardant 25m 650g PVC Coated Outdoor Event Tents
Alluminum Alloy Outdoor Event Tents Powder Coated Waterproof
Detailed Specification
1. Frame material: High-strength aluminum alloy 6061/T6.
2. Roof cover/triangle cloth: Double PVC-Coated Polyester, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
3. Side wall weight:650g/sqm
4. Roof cover weight :850g/sqm
5. Frame connection: Hot-dip galvanized steel structure
6. Allowed temperature condition: -30 degree Celsius+70 degree Celsius
7. Wind load: max. 100km/h (can be reinforced)
8. Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
9. Easy to be assembled and dismantled, movable.
Size Specification
1. Size: from 3 meters to 50meters
2. Eave height: standard from 2.5m, 3m, 4m to 5m upon span width (or special height per requested)
3. Length: Unlimited, extended by 3m or 5m each bay
| Span(width) | Side height | Ridge height | Longest part | Main profile(mm) | Bay distance |
| 3m | 2.5m | 3m | 2.7m | 36*71*2.5 | 3m |
| 6m | 2.5m | 3.5m | 3.2m | 48*84*3 | 3m |
| 8m | 2.5m | 3.9m | 4.3m | 48*84*3 | 3m |
| 9m | 2.5m | 4.1m | 4.8m | 48*84*3 | 3m |
| 10m | 2.5m | 4.3m | 5.3m | 48*84*3/48*100*3 | 3m |
| 12m | 3m | 5m | 6.3m | 68*122*3 | 5m |
| 15m | 3m | 5.4m | 7.9m | 108*150*3 | 5m |
| 18m | 3m | 5.9m | 9.5m | 112*203*4 | 5m |
| 20m | 4m | 7.2m | 10.6m | 112*203*4 | 5m |
| 25m | 4m | 8m | 10.6m | 112*203*4 | 5m |
| 30m | 4m | 8.8m | 10.6m | 113*259*5 | 5m |
| 35m | 4m | 9.6m | 10.6m | 120*300*5 | 5m |
| 40m | 4m | 10.5m | 11.1m | 120*300*5 | 5m |
| 45m | 4m | 11.3m | 11.1m | 128*350*5 | 5m |
| 50m | 4m | 12.2m | 11.1m | 128*350*5 | 5m |
| The length can be extended by 3m such as 6m,12,18m,30m... or by 5m bay such as 15m,20m,30m,40m... Customized size or shape is available | |||||
Application
the optimal choice of the outdoor parties, weddings, banquet, meeting, exhibitions, shows, hospitality, fetes, events, arenas, walkways, garaging, storage, stabling, etc.
Easy up tent structure
PVC material simply slots into channels in the aluminum framework - no bungee straps or ties are required.
Features
1. temporary or permanent use. global hoy-sale!
2. anti-aging, water proof, mildew-proof , heat preservation,tear-resistant,flame retardant.
3. Beautiful appearance, generous, durable, fashion
Professional Large Outdoor Marquee Wedding Event Tents For SaleProfessional Large Outdoor Marquee Wedding Event Tents For Sale
1) High security
2) Heavy-duty and stable structure
3) Elegant and magnificent appearance
4) TUV rheinland ISO9001:2008 certificated
5) No interior poles structure design ,to give 100% use of interior space
6) Easy to assemble and demount .Convenient to transport and storage
7) Frame: Reinforced aluminum alloy 6061/T6
Frame connector: Steel frame with plating processing
Fabric: PVC fabric / Transparent PVC fabric, 100% waterproof
Wind load: max. 100km/h
