20 Meter Width Emergency Medical Tents Aluminum Frame Outdoor Vaccination Marquee

20 Meter Width Aluminum Frame Outdoor Medical Vaccination Tent Marquee

Liri Prefabricated Medical Tent can perfectly meet the medical temporary and emergency use with the key strengths of easily assemble , speed, resue, flexible, all weather operated. Besides, for meeting medical purpose, ventilation windows, ventilation fan, doors, airconditioning, partition for room etc are optional.

Optional size:

Liri Tent series:


Optional accessories:


covers: Colorful cover, transparent cover, inflatable roof cover.

sidewalls: Glass wall, PVC hard wall, sandwich panel wall, fiber glass wall, ABS wall.

windows: Dome or square clear PVC windows, mesh window, glass window.

doors: Double-swings glass door, single-swing glass door, glass fire door, hard PVC door, rolling door


Others: wooden flooring system, rain gutters (inner roof beam rain gutter or rain gutter between two tents), lighting, AC, carpet, etc.

Material Decoration:

• Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.
• Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
• Connector: strong hot-dip galvanized steel
• Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
• Wind load: max. 100km/h (can be reinforced)
• Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)
• Easy to be assembled and dismantled, movable.
• No pole inside, 100% available interior space.

• If it is concrete ground , pls use the expandable bolts
• If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
• If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
• If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm

Packaging:

• aluminum frame packed in membrane film
• hardware packed in solid carton box
• roof and sidewall in professional PVC carry bag

advanced tents technology into our own design. Our main products include Modular Aluminium Alloy Structure Tents, Clear Span Tent Structure and Aluminium Alloy Square Pagoda & Summer Gazebo.Relying strong tech support and strict quality supervison, Liri Tent has providing tent to more than 130 countires and honor to provide service for WTA, F1, Canton fair, European games, Hollywood.
