Plain PVC Sidewalls Aluminium Pagoda Tent For National Games PRC
LIRI Aluminium Small Pagoda Tents With Plain PVC sidewalls For National Games of PRC
Quick Details
- Place of Origin:Guangdong, China
- Brand Name:LIRI TENT
- Model Number:PAG4/250
- Frame:hard pressed extruded aluminum alloy
- Side Wall:PVC walls,glass wall,ABS wall,sandwich panel wall,etc.
- Roof Cover:850g/sqm double PVC-coated polyester textile
- Connectors:Hot-DIP Galvanized
- Ground Situation:grassland,earth land,asphalt,cement ground,marble,etc.
- Roof Fixing:bar tensioning
- Fixing Solution:ground anchor, expandable bolt, weight plate, etc.
- Wind Resistance:80km/h
- Temperature Resistance:-30 degree Celsius ~ +70 degree Celsius
- Service Life:More than 15 years
| Item | Width | Eave Height | Ridge Height | Main Profile |
| PAG | 3m | 2.5m | 4.3m | 65x65x2.5mm |
| PAG | 4m | 2.5m | 4.8m | 65x65x2.5mm |
| PAG | 5m | 2.5m | 5.43m | 65x65x2.5mm |
| PAG | 6m | 2.5m | 5.92m | 65x65x2.5mm |
| PAG | 8m | 2.6m | 5.36m | 65x65x2.5mm |
| PAG | 10m | 2.6m | 6.38m | 65x65x2.5mm |
Pagoda tent can be used as a single unit or combined by a rain gutter to make a larger space or a special structure style. Customized size or shape is available.
| Main Profile |
Material: Hard pressed extruded aluminium 6082-T6, 6061/T6 Features: Stainless |
| Cover |
Material: Double PVC-coated polyester textile, 750g- 900g/m² Features: Waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant |
| Eave Connection | Hot-dip Galvanized steel insert |
| Wind Loading | Wind Loading |
Supply Ability
100000 Square Meter/Square Meters per Month Aluminium Small Pagoda Tents
Purposes
Can be widely used in expo, living, garden, party and epidemic prevention, etc
