Adhesion Testers - Cross Cut Adhesion Tester - Paint film adhesion tester

The HUATEC Adhesion Test Kit determine the adhesion of new and old paint layers on wood and woodlike materials. The damage on the substrate will be reduced to a minimum. The adhesion is judged by comparing the removed paint on the tape, and the remaining paint on the wood with the illustrations classifying the damage from class 0 to 5. Delivery includes cutting tool and tape.

The Tape For Adhesion Test can be ordered separately as well.

Specification:

• Dimensions: 100 * 55 mm
• Adhesion Test Scales
• Wet film thickness test(50-160μm, in steps of 10μm).
• Levelling test(1, 1.5 and 2mm)
• Film applicator(0-180μm, in steps of 20μm).
• Edge radius 2, 3, 4 and 5mm
