TG-8829FN Car Industry Dry Film Coating Thickness Gauge
TG-8829FN Car Industry Dry Film Coating Thickness Gauge
Description:
Operating principle: magnetic induction/eddy current (F/NF)
With separate probe(s)
Auto power off
Application:
1. Coating thickness gauge TG-8829F can measure the thickness of non-magnetic coating layers (aluminum, chrome, copper, ename1, rubber, paint) on magnetic substrate (steel, iron, alloy and magnetic stainless steel)
2. Coating thickness gauge TG-8829N can measure the thickness of non-conductive coating layers (ename1, rubber, paint, vanish, plastic anodic oxide layer) covered on non-ferrous substrate (aluminum, brass, zinc, tin and non-magnetic stainless steel)
| Measuring range | 0-1250um/0-50mil |
| Resolution | 0.1/1 |
| Accuracy | ±1-3%n or ±2.5um |
| Min. measuring area | 5mm |
| Min. sample thickness | 0.3mm |
| Battery indicator | low battery indicator |
| Metric/ imperial | convertible |
| Power supply | 4x1.5V AAA(UM-4)battery |
| Operating conditions | 0-+45℃(32℉-104℉),≤90%RH |
| Dimensions | 124x62x30mm |
| weight | 115g |
Standard Delivery:
Main unit 1
F type probe 1
N type probe 1
F calibration base set 1
N calibration base set 1
Calibration foil set 1set (4 foils)
Carrying case 1
Instruction manual 1
Optional Accessories:
Cable and software for RS-232C
Customized testing range
