TS6 Working Hydraulic Mobile Scissor Lift 7.8m Workshop Electric Motor Stationary

Price Negotiable
Price: Negotiation
MOQ: 1 set
Delivery Time: 45 working days after received your payment
Brand: Tysim
Product Description







Model TS6
Size Dimension
(A)Max Working Height 7.8m
(B)Max Platform Height 5.8m
(C)Platform Height-Stowed 1m
Platform-Length 1.58m
-Length extended 2.48m
Platform Extended 0.9m
(D)Platform Width-outside 0.74m
Rail Height 1.1m
Toe-guard Height 0.13m
(E)Height-Stowed:(rail unfolded) 2.1m
(rail folded) 1.75m
(F)Length-Stowed 1.78m
Length-extended 2.66m
(G)Width 0.81m
(H)Wheelbase 1.3m
(I)Ground Clearance
(Pothole protection lay down)
2cm
(J)Ground Clearance 7cm
Performance
Platform Occupancy (indoor/outdoor) 2/0
Wind Speed 0m/s
Platform Capacity 230kg
Extension Platform Capacity 120kg
Drive Speed-Stowed 3.5km/h
Drive Speed-Raised 0.8km/h
Gradeability-Stowed 25%
Turning Radius-inside 0
Turning Radius-outside 1.6m
Raise/Lower Speed 21s/32s
Control Proportional
Drive Mode Double front wheel
Non-marking tire(Dia. x W) 323×100
Power
Power Source 24VDC
  4x6V battery
Hydraulic System Capacity 8L
Noise Vibration
Sound pressure level(ground) <70dB
Sound pressure level(platform) <70dB
Vibration <2.5m/s²
Weight 1200kg
CE Standard EN280



Why Choose Us?

1. We are the first factory to design & manufacture pile breaker in China with over 5 years.

2. We have the Patent for Invention of Hydrauilc Pile Breaker in China.

3. Our pile breakers have been sold to more than 20 countries, with good feedback.

4. Using best material, our pile breaker is the best quality.

FAQ

Q1: Are you a trading company or a manufacturer?
A1: We are a professional manufacturer, and our factory mainly produces hydraulic pilling rig, hydraulic pile breaker, telescopic arm and related piling equipment etc. Our products have been exported to more than 50 countries of Asia, South America, Africa,and have developed a good world wide reputation.

Q2:What kind of product certification do you have?
A2: All our products have passed ISO9001 and CE certifications and also passed the inspection by the Chinese National Construction Machinery Quality Inspection Center. We have strict quality inspection process including a load test for every machine before leaving our factory in order to offer the best quality machines to our customers

Q3: Do you have after sales service?
A3:Yes, we have special service team which will offer you professional guidance. If need be, we can dispatch our engineer to your worksite to provide training for your staff.

Q4:Do you test all your goods before delivery?
A4 :Yes, we have strict quality inspection process including a load test for every machine before leaving our factory.
