BONNY 48ton 250kw 6000V Electric Hydraulic Crawler Excavator CED480-8
BONNY 48ton CED480-8 Electric Hydraulic Crawler Excavator for sale
1.Place of Origin:Wuxi, China (Mainland)
2.Brand Name:BONNY
3.Model Number:CED480-8
4.Condition:New
5.Moving Type:Crawler Excavator
6.Operating Weight:48t
7.Bucket capacity:1.6~2.5m³
8.Maximum Digging Height:10965mm/9920mm
9.Maximum Digging Depth:7760mm/2770mm
10.Machine Weight:48t
11.Max Digging Radius:12018mm/8550mm
12.Rated Speed:3.6 km/h
13.Certification:ISO9001
14.After-sales Service Provided:Engineers available to service machinery overseas
15.Electromotor:YJK3554-4
16.Rated Power:250kw
17.Voltage:6000V
18.Max.torque:1219 Nm
19.Max. pulling force:360kN
20.Type of undercarriage:H structure
| No. | Item | Unit | Data | ||
| Backhoe | Face shovel | ||||
| 1 | Machine weight | t | 48 | 50 | |
| 2 | Electromotor | Rated power | kW | 250 | |
| Rated voltage | V | 6000 | |||
| Rated speed | r/min | 1480 | |||
| 3 | Hydraulic system | System pressure | MPa | 32 | |
| Max. flow | L/min | 2×401 | |||
| 4 | Swing device | Swing speed | r/min | 8.3 | |
| Tail swing radius | mm | 3874 | |||
| 5 | Pilot system | System pressure | MPa | 4 | |
| System flow | L/min | 21.5 | |||
| 6 | Traveling device | Traveling speed | km/h | 3.62 | |
| Ground pressure | MPa | 0.0987(560mm track pad) | |||
| Pulling force of the | kN | 2×353.32 | |||
| 7 | Working parameters | Boom specification | mm | 7060 | 4100 |
| Stick specification | mm | 3380 | 2700 | ||
| Bucket capacity of backhoe | m3 | 2.1 | 2.5 | ||
| Max. digging reach | mm | 12018 | 8550 | ||
| Max. digging depth | mm | 7760 | 2270 | ||
| Max. digging height | mm | 10965 | 9920 | ||
| Max. dumping height | mm | 7655 | 7370 | ||
| Max. digging force of stick | kN | 217 | 269 | ||
| Max. digging force of bucket | kN | 236 | 271 | ||
Applied
- The technique powered by 6000V high voltage power supply.
- Intellectual technology such as malfunction diagnose,monitoring
- GPS real time remote monitoring system
- The technology for application in extreme cold region
- The technology for application at high altitude
- The technology suitable to application on all kinds of mines.
New material
Working attachment is made of high strength steel plate and castings which are applicable for the harsh mining operation.
Bucket cutting part of HARDOX Wear-resistant steel and ESCO teech insures long operation life of bucket even under harsh condition on mining site.
Customizing manufacturing based on indivdual operating situation
Environment temperature:
- according to different operating area
- customizing design on power unit(cold starting,different oil products)
- hydraulic system(components,hoses,seals,oil products),electric system(reliability)
- working attachment(steel sheet,teeth)
- cab(human protection,heating)
- welding and coating system of machines to meet requirements under extreme conditions.
