Ford Truck, Iveco-Fiat EuroCargo K24 Turbo 53249886405 turbo Actuator valve wastegate
Ford Truck, Iveco-Fiat EuroCargo K24 Turbo 53249886405 turbo Actuator valve wastegate
| Part Number | 53249886405 |
| Previous Part Number | 5324-988-6405, 5324 988 6405 |
| OE number | 4848601, 99446021, 2992392 |
| Description | Truck Ford EuroCargo, Iveco Eurocargo |
| Manufacturer Part Number | 53249706405, 5324-970-6405, 5324 970 6405 |
| CHRA | 53247100018 (5324-710-0018) |
| Turbo Model | K24-2464GGA5.51GBATD |
| Engine | 8040.45.4300 |
| Displacement | 3.91L, 3900 ccm |
| KW | 100/136 HP |
| RPM Max | 2700 |
| Fuel | Diesel |
| Angle α (compressor housing) | 312� |
| Angle β (turbine housing) | 240� |
| Bearing Housing | 53241500019 |
| Turbine Wheel | 53241205001/53241202109 (53241202103, 53241202102) (Ind. 50. mm, Exd. 59 mm, 12 Blades) |
| Comp. Wheel | 53241232012/53241232017/53241232014/53241232000 (Ind. 36.2 mm, Exd. 60.5 mm, 6+6 Blades, Flat back) (1301024400) |
| Back plate | 53241515703 (409629-0006) |
| Heat shield Number | 53241652003 (409627-0000) |
| Repair Kit | 53247110027/53277110020 (1301027751) |
| Turbine Housing | 53241007027/53241017028 |
| Compressor Cover | 53241015206 |
| Turbine Housing AR | 5 |
| Actuator Waste gate valve | 58061100338 |
| settings Waste gate (pressure) | 1.05 bar |
| settings Waste gate (lift shaft) | 3.20 mm |
| NOTE | Intercooler |
| Replaces | 465379-0003 |
| Manufacturer | Borg Warner - 3K - Schwitzer |
Appliions
1995-05 Ford Truck, Iveco-Fiat EuroCargo 75.14 with 8040.45.4300 Engine
2002-09 Iveco-Fiat EuroCargo with 8040.45.4300 Engine
Pictures:
Contact:
Email/Skype:costelturbo@outlook.com
What items can supply:
A, currently supplies over 220 different actuators, which includes Pressure acutators, Pneumatic actuators, Vacuum actuators with position sensors, and so on.
B, The replacement actuators cover many popular originally manufactured turbos.
C, Electrical Actuators Parts, including Motors, Worm Gear, Loing Lug, Gearboxes etc.
D, Permeability test 100%.
E, Spring liner data test 100%.
Products coverage:
- Garrett(GT12,GTC14,GT15-25,GT37,GT42,GT45 etc),
- KKK (K03,K04,K06,K16,K27,K31,KP35,KP39,BV43,BV50,R2S etc),
- Schwitzer (S1B/S100,S2B/S200,S300,S400 etc),
- MHI (TD02,TF035,TD04,TD05,TD06 ,TD07,TD08 etc),
- Holset(HX30,HX35/HE341,HX40/HE431V,HX55/HE551,HT60,HX80 etc),
- IHI (RHF/RHB3,RHF/RHB4,RHF5/RHB5,RHG6,RHG7,RHG8 ,RHG9 etc),
- Toyota (CT9,CT10,CT12,CT16V,CT20,CT26 etc).
