Alloy 4343 / 3003 + 0.5% Cu / 5005 Aluminum Heat Transfer Sheets Moderate Strength
Alloy 4343/3003+0.5%Cu/5005 Aluminum Heat Transfer Sheets With Moderate Strength For Radiator Heater Plates
Core Material
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.5 | － | 0.1 | 0.05 | 0.03 |
Cladding Material
| Alloy | Si | Fe | Cu | Mn | Mg | Zn | Zr | Ti | code |
| 4343 | 6.8- 8.2 | 0.8 | 0.25 | 0.1 | - | 0.20 | － | 0.05 |
|
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.5-1.0 | - | 0.03 |
Produce capability
| Width(mm) | Thickness(mm) | Length(mm) | Inside Diameters(mm) | |
| Sheet | 500-1070 | 0.5-5.0 | 500-2500 | As customer request |
Strength of Plates
| Pre-Braze Strenght ( Mpa) | Post - Braze Strength ( Mpa ) |
|
Alloy
|
Temper | Yield Strength | Tensile Strength | Temsile Strength | Yield Strength |
|
4343/3003+0.5%Cu/5005
|
HO | > / = 45 | 120 -150 | 135 | 45 |
Our Advantage:
1. Manufacturer and Distributer, we can supply different brand and series plate and gasket,
2. As manufacturer, we can supply the best quality replace parts for above brands to help you save cost.
3. Over 10 years experience on the energy field, we also can provided technical service such as technical consultation, equipment update, capacity expansion scheme, maintenance and cleaning of the equipment.
4. ISO9001:2008 international quality standard certification.
5. One year lifetime guarantee.
6. High quality and competitive price , fast delivery.
